SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

AL100
The AL100 is a high output, 104dB(A) alarm sounder combined with a 5 Joule Xenon strobe beacon or LED
beacon. The compact, robust housing is ideal for all general signalling applications including fire, security
and process control.
Sounder and Beacon, 104Db, 32 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
Supply Voltage LED 12Vdc, 24Vdc, 48Vdc, • Continuously rated.
115Vac, 230Vac • Stainless steel fixings.
MAX/MIN Output 104dB/93dB • Unit can be mounted using external lugs or
Measurements 172 x 86 x 83 mm internal BESA compatible fixing positions.
• Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request.
Also available as telephone initiated and synchronized
units. • Available with custom tone configurations
and frequencies. Lens colours:
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages
*Not available with LED. Housing colours:
IP

0,6kg 66 -25º/+55ºC Industry Fire EL Sounder Xenon LED

AL105N
The AL105N is a high output, 112dB(A) alarm sounder combined with a 5 Joule Xenon beacon. The robust,
fire retardant IP66 housing ensures the AL105N is suitable for all general signalling applications including
fire, security and process control.
Sounder and Beacon, 112Db, 32 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
MAX/MIN Output 112dB/102dB • Continuously rated.
Measurements 214 x 130 x 132 mm • Stainless steel fixings.
• Unit can be mounted using external lugs or
internal
Also available as telephone initiated and synchronized BESA compatible fixing positions.
units. • Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations Lens colours:
and frequencies.
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages Housing colours:

IP

1,2kg 66 -25º/+55ºC Industry Fire EL Sounder Xenon LED

AL112N
The AL112N is a high output, 119dB(A) alarm sounder combined with a 5 Joule Xenon beacon. The robust,
01 - INDUSTRY & MARINE COMBINED
fire retardant IP66 housing ensures the AL112N is suitable for all general signalling applications including
fire, security and process control.
Sounder and Beacon, 119Db, 45 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
MAX/MIN Output 119dB/106dB • Continuously rated.
Measurements 252 x 168 x 155 mm • Stainless steel fixings.
• Unit can be mounted using external lugs or
internal BESA compatible fixing positions.
Also available as telephone initiated and synchronized • Duplicate cable terminations (in & out for daisy-
units. chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations
and frequencies. Lens colours:
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages
- User configurable continuous frequency tone. Housing colours:
IP

2,3kg 66 -25º/+55ºC Industry Fire EL Sounder Xenon
