PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

AL121
The AL121 is a high output, 126dB(A) alarm sounder combined with a 5 Joule Xenon beacon. The robust,
fire retardant IP66 housing ensures the AL121 is suitable for all general signalling applications including
fire, security and process control.
Sounder and Beacon, 119Db, 45 Tones Features
Light sources Xenon • Automatic synchronisation on multi-sounder
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, system.
115Vac, 230Vac • Continuously rated.
MAX/MIN Output 126dB/113dB • Stainless steel fixings.
Measurements 274 x 190 x 210 mm • Unit can be mounted using external lugs or
internal BESA compatible fixing positions.
Also available as telephone initiated and synchronized • Duplicate cable terminations (in & out for
units. daisy-chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations
and frequencies. Lens colours:
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages
- User configurable continuous frequency tone. Housing colours:
IP

2,9kg 66 -25º/+55ºC Industry Fire EL Sounder Xenon

AB105 Combined
The AB105 combines a high output 112dB(A) alarm sounder with a powerful 5J Xenon strobe warning
beacon, multi-function LED beacon or a 25W halogen rotating beacon. The beacon and sounder can be
operated from the same power source or controlled individually.

Sounder and Beacon, 112Db, 32 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
Supply Voltage LED 10-50Vdc, 115Vac, 230Vac • Continuously rated.
Supply Voltage Rotating 10-30Vdc, 115Vac, 230Vac • Stainless steel fixings.
MAX/MIN Output 112dB/100dB • Unit can be mounted using external lugs or internal
Measurements 274 x 144 x134mm BESA compatible fixing positions.
• Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Lens colours:
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages
- User configurable continuous frequency tone. Housing colours:

IP

2,9kg 65 -25º/+55ºC Industry Fire EL Sounder RPM 180 Xenon LED

AB112 Combined
The AB112 combines a high output 119dB(A) alarm sounder with a powerful 5J Xenon strobe warning
beacon, multi-function LED beacon or a 40W halogen rotating beacon. The beacon and sounder can be
operated from the same power source or controlled individually.
Sounder and Beacon, 119Db, 45 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
Supply Voltage LED 10-50Vdc, 115Vac, 230Vac • Continuously rated.
Supply Voltage Rotating 10-50Vdc, 115Vac, 230Vac • Stainless steel fixings.
MAX/MIN Output 119dB/107dB • Unit can be mounted using external lugs or
Measurements 313 x 190 x157mm internal BESA compatible fixing positions.
• Duplicate cable terminations (in & out for daisy-
chain installations). 01 - INDUSTRY & MARINE COMBINED
• Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Lens colours:
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages
- User configurable continuous frequency tone. Housing colours:
IP

1,25kg 65 -25º/+55ºC Industry Fire EL Sounder RPM 180 Xenon LED
