SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

SON4
The SON4 is a compact, high output, 104dB(A) alarm sounder with integral Xenon strobe beacon, L.E.D.
array or filament bulb. The robust fire retardant housing ensures the SON4 is suitable for all general
signaling applications including fire, security and process control.
Sounder and Beacon, 100dB, 32 Tones Features
Supply Voltage Xenon 24Vdcm 24Vac, 115Vac, • Automatic synchronisation on multi-sounder
230Vac system
Supply Voltage LED 12Vdc, 24Vdc, 48Vdc, • Continuously rated
24Vac, 115Vac, 230Vac • Stainless steel fixings
Supply Voltage Filament 24Vdc 24Vac, 115Vac, • Unit can be mounted using external lugs or
230Vac internal BESA compatible fixing positions
MAX/MIN Output 100dB/96dB • Duplicate cable terminations (in & out for daisy-
Measurements 86*86*102mm chain installations)
• Wire to base installation
• Tropicalisation available on request
• Available with custom tone configurations and Lens colours:
frequencies.
* Not available with LED
Housing colours:
IP

0,4kg 66 -25º/+55ºC Industry Fire EL Sounder Xenon LED Filament

SONFL1
The SONFL1 is a compact 100dB(A) alarm sounder combined with a 5 joule Xenon strobe beacon. The IP66
housing is ideal for all general signaling applications including fire, security and process control.
Sounder and Beacon, 100Db, 10 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc, 24Vac, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system
Supply Voltage LED 12Vdc, 24Vdc, 115Vac, • Continuously rated
230vac • Stainless steel fixings
MAX/MIN Output 100dB/96dB • Unit can be mounted using external lugs or
Measurements 86 x 86 x 83 mm internal BESA compatible fixing positions
• Duplicate cable terminations (in & out for daisy-
chain installations)
• Wire to base installation
• Tropicalisation available on request
• Available with custom tone configurations
and frequencies. Lens colours:
Also available as telephone initiated and
synchronized units.
* Not available with LED Housing colours:

IP

0,5kg 66 -25º/+55ºC Industry Fire EL Sounder Xenon LED Filament

STA Alarm tower
The STA2, STA3 and STA4 are customisable audio-visual signals featuring a tower of 2, 3 or 4 AlertAlight
01 - INDUSTRY & MARINE COMBINED
L101 type beacons combined with a SONF1 alarm sounder. Each beacon position can contain either a
Xenon or high output L.E.D. light source. The STA2, STA3 or STA4 assembly features a prewired junction
box and cable loom enabling the end user to determine beacon type and position during installation.
Sounder and Beacon, 100Db, 10 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc, 115Vac, • SONF1 alarm sounder synchronises
230Vac automatically on multi-unit systems.
Supply Voltage LED 10-30Vdc, 90-260Vdc/ac • Multiple configurations of Xenon and LED
MAX/MIN Output 100dB / 99dB beacons.
Measurements 86*86*83mm pr. piece • Internal cable loom and termination PCB
simplifies installation.
• Common negative/neutral supply minimises
cabling.
• High output LED unit can be set to steady or
flashing. Lens colours:
• Also available without SONF1 audible signal -
see the STB2/3/4 data sheet (2.1.021v10a).
Also available as telephone initiated and
synchronized units. * Not available with LED Housing colours:
IP

0,5kg 66 -25º/+55ºC Industry Fire Traffic Junction Box EL Sounder Xenon LED Filament
