SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

AB121 Combined
The AB121 combines a high output 126dB(A) alarm sounder with a powerful 5J Xenon strobe warning
beacon, multi-function LED beacon or a 40W halogen rotating beacon. The beacon and sounder can be
operated from the same power source or controlled individually.
Sounder and Beacon, 126Db, 45 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
Supply Voltage LED 10-50Vdc, 115Vac, 230Vac • Continuously rated.
Supply Voltage Rotating 10-30Vdc, 115Vac, 230Vac • Stainless steel fixings.
MAX/MIN Output 126dB/113dB • Unit can be mounted using external lugs or
Measurements 389 x 190 x191mm internal BESA compatible fixing positions.
• Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations
and frequencies. Lens colours:
• ‘Programmable’ version available:
- 45 alarm tones
- 4 remotely selectable stages
- User configurable continuous frequency tone. Housing colours:
IP

2,7kg 65 -25º/+55ºC Industry Fire EL Sounder RPM 180 Xenon LED

MCA112 Combined
The MCA112-05 combines a high output, 119dB(A) alarm sounder with a 5 Joule Xenon beacon, or multi-
function LED. With a robust, fire retardant, IP66 & IP67 housing, the MCA112-05 is particularly suitable for
harsh environments with high ambient noise levels. The sounder & beacon can be operated individually or
simultaneously.
Marine Sounder and Beacon, 119Db, 45 Tones Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronisation on multi-sounder
115Vac, 230Vac system.
Supply Voltage LED 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronised flash, or Flip-Flop
115Vac, 230Vac alternating mode.
MAX/MIN Output 119dB/106dB • Xenon tube mechanically secured against
Measurements Ø181*385mm vibration.
• Continuously rated.
• Large termination area.
• Stainless steel fixings.
• Ratchet adjustable stainless steel ‘U’ bracket Lens colours:
for 360° positioning.
• Duplicate cable terminations.(in & out for daisy-
chain installations).
Housing colours:

IP

3,5kg 66/67 -25º/+55ºC Industry Fire Marine EL Sounder Xenon LED

MCB Dual Beacon
The MCB005-05 is a dual 5 Joule Xenon strobe beacon featuring a robust, fire retardant, IP66 & IP67
01 - INDUSTRY & MARINE COMBINED
housing; suitable for harsh environments. The unique design minimises installation time and allows the
beacons to be operated simultaneously from the single power source (either in synchronisation or in ‘flip-
flop’ mode) or independently.
Dual Marine Beacon Features
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, • Automatic synchronised flash, or Flip-Flop
115Vac, 230Vac alternating mode.
Supply Voltage LED 12Vdc, 24Vdc/ac, 48Vdc, • Xenon tubes mechanically secured against
115Vac, 230Vac vibration.
Measurements Ø166*345mm • Continuously rated.
• Large termination area.
• Stainless steel fixings.
• Ratchet adjustable stainless steel ‘U’ bracket
for 360° positioning.
• Duplicate cable terminations (in & out for daisy- Lens colours:
chain installations).
• Tropicalisation available on request.
Housing colours:

IP

1,48kg 66/67 -25º/+55ºC Industry Fire Marine Xenon LED
