AL105N Appello-X
The AL105NAX Appello X is the next generation of user recordable alarm sounder, capable of storing up
to 2 minutes of content, combined with either a Xenon strobe or high output LED beacon. The AL105NAX
records, stores and plays back with unsurpassed clarity, user defined voice messages, music or sounds
stored directly to non-volatile memory without any intermediate analogue to digital conversion.
User recordable alarm sounder and beacon Features
Maximum output 110dB(A) @ 1 metre • Direct content storage on non-volatile memory.
No. of tones 45 (UKOOA / PFEER • CD quality reproduction.
compliant) • Message length: 4 x 30 seconds
No. of Messages 4 (30 Seconds each) • Easy message creation with built in microphone
Supply Voltage Xenon 12VDc, 24VDc, 115Vac, or line-in audio input.
230VAc • Edits automatically to message length.
Supply Voltage LED 10-30VDc, 90-260VAc • DC versions have reverse polarity diode
Effective Range 60m @ 1KHz protection.
Measurements 133*144*216mm • Unit can be mounted using external lugs or
internal BESA compatible fixing positions. Lens colours:
• Volume controls for user content and alarm
tones.
• Available with custom tone configurations and
frequencies. Housing colours:
IP

1,2kg 66 -25º/+55ºC Industry Fire Marine Bell Loudspeaker Buzzer EL Sounder LED Xenon

AL121 Appello-X
The AL121AX Appello X is the next generation of user recordable alarm sounder, capable of storing up to 2
minutes of content, combined with either a Xenon strobe or high output LED beacon. The AL121AX records,
stores and plays back with unsurpassed clarity, user defined voice messages, music or sounds stored
directly to non-volatile memory without any intermediate analogue to digital conversion.
User recordable alarm sounder and beacon Features
Maximum output 126dB(A) @ 1 metre • Direct content storage on non-volatile memory.
No. of tones 45 (UKOOA / PFEER • CD quality reproduction.
compliant) • Message length: 4 x 30 seconds
No. of Messages 4 (30 Seconds each) • Easy message creation with built in microphone
Supply Voltage Xenon 12VDc, 24VDc, 115Vac, or line-in audio input.
230VAc • Edits automatically to message length.
Supply Voltage LED 10-30VDc, 90-260VAc • DC versions have reverse polarity diode
Effective Range 300m @ 1KHz protection.
• Unit can be mounted using external lugs or
Measurements 190*191*276mm
internal BESA compatible fixing positions. Lens colours:
• Volume controls for user content and alarm
tones.
• Available with custom tone configurations and
frequencies. Housing colours:
IP

1,2kg 66 -25º/+55ºC Industry Fire Marine Bell Loudspeaker Buzzer EL Sounder LED Xenon
