PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

MCL15-05
The MCL15-05 combines a 15W PA horn loudspeaker with a 5 Joule Xenon beacon. With a robust, fire
retardant, IP66 & IP67 housing, the MCL15-05 is particularly suitable for harsh environments with high
ambient noise levels.
PA Horn Speaker and Beacon, 118Db, 15W Features
Supply Voltage Xenon 12Vdc, 24Vdc, 48Vdc, • Automatic synchronised flash, or Flip-Flop
115Vac, 230Vac alternating mode.
Impedence/Tappings 8/16Ohm, 70v/100V Line • Xenon tube mechanically secured against
MAX/MIN Output 119dB/106dB vibration.
Measurements Ø181*385mm • Continuously rated.
• Large termination area.
• Stainless steel fixings.
• Ratchet adjustable stainless steel ‘U’ bracket
for 360° positioning.
• Duplicate cable terminations (in & out for daisy-
chain installations). Lens colours:
• Tropicalisation available on request.

Housing colours:
IP

3,5kg 66/67 -25º/+55ºC Industry Fire Marine Loudspeaker Xenon LED

HAB105 Combined
Applications and users that have traditionally demanded conventional electromechanical hooters, sirens,
buzzers and bells can now choose the next generation alternative. The Hootronic series of products
faithfully reproduce the sounds made by legacy electro-mechanical signaling devices but in a modern,
reliable and cost effective way. With output levels of up to 112dB(A) at 1 metre the HAB105TRH surpasses
legacy electro-mechanical devices in performance and effectiveness, it is also continuously rated,
requires zero maintenance and the signal quality will not degrade with age.
Siren, Buzzer, Hooter and Beacon, 112Db, 5 Tones Features
Supply Voltage Rotating 10-30Vdc, 115Vac, 230Vac The products in the Hootronic range have 5 user
MAX/MIN Output 112dB/100dB selectable ‘traditional’ sounds including:
Measurements 274 x 144 x134mm • Tone 1 : Industrial Hooter, Tone 2 : High
Frequency Mechanical Siren
• Tone 3 : Medium Frequency Mechanical Siren,
Tone 4 : Electro Mechanical Buzzer
• Tone 5 : Mechanical Bell
Lens colours:
Each of these sounds have two additional,
remotely selectable, alarm stages. Remote switch
generates genuine ‘tail off’ to sound when alarm
is terminated. Housing colours:

IP

1,25kg 66 -25º/+55ºC Industry Fire RPM 180 Bell Motorsiren Buzzer

HAB121 Combined
Applications and users that have traditionally demanded conventional electromechanical hooters, sirens,
buzzers and bells can now choose the next generation alternative.The E2S Hootronic series of products
faithfully reproduce the sounds made by legacy electro-mechanical signalling devices but in a modern,
reliable and cost effective way.With output levels of up to 121dB(A) at 1 metre the HAB121RTH surpasses
legacy electro-mechanical devices in performance and effectiveness, it is also continuously rated,
requires zero maintenance and the signal quality will not degrade with age.
Siren, Buzzer, Hooter and Beacon, 121Db, 5 Tones Features
Supply Voltage Rotating 10-30Vdc, 115Vac, 230Vac The products in the Hootronic range have 5 user
MAX/MIN Output 121dB/113dB selectable ‘traditional’ sounds including:
Measurements 388 x 210 x192mm • Tone 1 : Industrial Hooter, Tone 2 : High
Frequency Mechanical Siren
• Tone 3 : Medium Frequency Mechanical Siren, 01 - INDUSTRY & MARINE COMBINED
Tone 4 : Electro Mechanical Buzzer
• Tone 5 : Mechanical Bell
Lens colours:
Each of these sounds have two additional,
remotely selectable, alarm stages. Remote switch
generates genuine ‘tail off’ to sound when alarm
is terminated. Housing colours:
IP

2,7kg 66 -25º/+55ºC Industry Fire RPM 180 Bell Motorsiren Buzzer
