PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

H100B Combined
Rated for continuous use the H100 series is a compact, high output signal suitable for a variety of
installations. In addition to the ‘buzzer’ type sound the unit features a further two alarm sounds.
Sounder and Beacon, 100Db, 3 Tones Features
Supply Voltage Xenon 24Vdc, 24Vac, 115Vac, • Volume control.
230Vac • Stainless steel fixings.
Supply Voltage LED 12Vdc, 24Vdc, 115Vac, • Bayonet fixing lens.
230vac • Anti-tamper locking screw
MAX/MIN Output 100dB/96dB
Measurements Ø84*71,5 mm

Lens colours:

Housing colours:
IP

0,4kg 65 -25º/+55ºC Industry Fire EL Sounder Xenon LED Filament

H100T Combined
Rated for continuous use the H100 series is a compact, high output signal suitable for a variety of
installations. In addition to the ‘buzzer’ type sound the unit features a further two alarm sounds.
Trumpet horn and Beacon, 100Db, 3 Tones Features
Supply Voltage Xenon 24Vdc, 24Vac, 115Vac, • Volume control.
230Vac • Stainless steel fixings.
Supply Voltage LED 12Vdc, 24Vdc, 115Vac, • Bayonet fixing lens.
230vac • Anti-tamper locking screw
MAX/MIN Output 100dB/96dB
Measurements Ø84*71,5 mm

Lens colours:

Housing colours:

IP

0,5kg 65 -25º/+55ºC Industry Fire EL Sounder Xenon LED Filament

H110T Combined
The H110T is a very high output electronic signal horn capable of generating a traditional ‘buzzer’ warning
tone traditionally associated with electro-mechanical signals.
Trumpet horn and Beacon, 110Db, 3 Tones Features
Supply Voltage Xenon 24Vdc/ac, 24Vdc/ac,- • Volume control.
48Vdc/ac 115Vac, 230Vac • Stainless steel fixings.
Supply Voltage LED 12Vdc, 24Vdc, 48Vdc • Bayonet fixing lens.
115Vac/dc, 230Vac • Anti-tamper locking screw
Supply Voltage Rotating 12Vdc, 24Vdc, 115Vac,
230Vac
MAX/MIN Output 110dB/108dB
Measurements Ø84*71,5 mm 01 - INDUSTRY & MARINE COMBINED

Lens colours:

Housing colours:

IP

0,5kg 65 -25º/+55ºC Industry Fire EL Sounder RPM 180 Xenon LED Filament
