SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

HMCA112 Combined
Applications and users that have traditionally demanded conventional electromechanical hooters,
sirens, buzzers and bells can now choose the next generation alternative. The Hootronic series of
products faithfully reproduce the sounds made by legacy electro-mechanical signaling devices but in a
modern, reliable and cost effective way. With output levels of up to 122dB(A) at 1 metre the HMCA112-05
surpasses legacy electro-mechanical devices in performance and effectiveness, it is also continuously
rated, requires zero maintenance and the signal quality will not degrade with age.
Marine Siren, Buzzer, Hooter and Beacon, 122Db, Features
5 Tones The products in the Hootronic range have 5 user
Supply Voltage Xenon 12Vdc, 24Vdc/ac, 48Vdc, selectable ‘traditional’ sounds including:
115Vac, 230Vac • Tone 1: Industrial Hooter,
MAX/MIN Output 122dB/112dB • Tone 2: High Frequency Mechanical Siren
Measurements Ø181*385mm • Tone 3: Medium Frequency Mechanical Siren,
• Tone 4: Electro Mechanical Buzzer
• Tone 5: Mechanical Bell
Lens colours:
Each of these sounds have two additional,
remotely selectable, alarm stages. Remote switch
generates genuine ‘tail off’ to sound when alarm
is terminated. Housing colours:
IP

3,5kg 66/67 -25º/+55ºC Industry Fire Marine Bell Motorsiren Buzzer Xenon

LEDA125
This beacon type offers maximum flexibility in terms of visual and audible requirements. The beacon
can produce 3 colours, Amber, Green and Red in conjunction with an audible signal. Two piezo sounders
situated in the base of the unit can be synchronised with any colour and flash rate required. The unit
requires PLC control to function. Ideally suited to status control the beacon is a cost effective alternative
to the traditional tower light. An M12 sealing grommet in the base allows for cable entry and termination
inside the enclosure. Maximum cable size is 5mm.
Tri-Colour Audible Beacon, 90Db, 1 Tones Features
Supply Voltage LED 24Vdc • Tri-colour
MAX/MIN Output 90dB/90dB • LED Long life
Measurements 252 x 168 x 155 mm • Extra bright
• Combined audible & visual signal
• 360° visibility

Lens colours:

Housing colours:

IP

0,4kg 65 -25º/+55ºC Industry Fire EL Sounder LED

444 Combined
The 444 is a high output, 114dB(A) alarm sounder combined with LED beacon. The compact, robust
01 - INDUSTRY & MARINE COMBINED
housing is ideal for all general signalling applications including fire, security and process control. It`s neat
design makes it usable also in public areas.
Electronic Sounder and Beacon, 114Db, 32 Tones Features
Supply Voltage LED 24Vdc, 115Vac, 230Vac • LED Long life
MAX/MIN Output 114dB/90dB • Extra bright
Measurements 150 x 113 x 109 mm • Combined audible & visual signal
• 360 °visibility

Lens colours:

Housing colours:

IP

0,4kg 65 -25º/+55ºC Industry Fire EL Sounder LED
