SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

A105N Appello-X
The A105NAX Appello X is the next generation of user recordable alarm sounder capable of storing up
to 2 minutes of content. The A105NAX records, stores and plays back with unsurpassed clarity, user
defined voice messages, music or sounds stored directly to non-volatile memory without any intermediate
analogue to digital conversion. Low current consumption and CD quality reproduction in a robust fire
retardant Type 4/4X/3R/13, IP66 housing ensure the A105NAX Appello X is suitable for all general
signalling applications including fire, security and process control.
User recordable alarm siren Features
Maximum output 110dB(A) @ 1 metre The A105NAX Appello user recordable unit enables the end
user to record any type of content such as voice or music that
No. of tones 45 (UKOOA / PFEER can then be played back at CD quality output at SPL’s of up
compliant) to 102dB(A) at 1 metre. The user recordable content can be
No. of Messages 4 (30 Seconds each) reproduced repeatedly, alternating with or without one of the
built-in 45 alarm tones. The alarm tone notification has an
Supply Voltage 10-30VDc, 90-260VAc output of up to 110dB(A) at 1 metre. The user defined content
Effective Range 60m @ 1KHz can be recorded by either using the on-board microphone or
Measurements 130*130*133mm through the ‘line-in’ audio Input using the supplied 3.5mm
audio cable from devices such as a PC, MP3 or CD player.
For multiple unit installations the recording process is only Colours:
required once to create a master unit which can then be used
to program all other A105NAX units on the system using the
supplied ‘Synch’ cable, thereby Guaranteeing synchronization
during playback.
IP
1,0kg 66 -25º/+55ºC Industry Fire Marine Bell Loudspeaker Buzzer EL Sounder

A121 Appello-X
The A121AX Appello X is the next generation of user recordable alarm sounder capable of storing up to
2 minutes of content. The A121AX records, stores and plays back with unsurpassed clarity, user defined
voice messages, music or sounds stored directly to non-volatile memory without any intermediate
analogue to digital conversion. Low current consumption and CD quality reproduction in a robust fire
retardant Type 4/4X/3R/13, IP66 housing ensure the A121AX Appello X is suitable for all general signalling
applications including fire, security and process control.
User recordable alarm siren Features
The A121AX Appello user recordable unit enables the end
Maximum output 126dB(A) @ 1 metre user to record any type of content such as voice or music that
No. of tones 45 (UKOOA / PFEER can then be played back at CD quality output at SPL’s of up
compliant) to 112dB(A) at 1 metre. The user recordable content can be
No. of Messages 4 (30 Seconds each) reproduced repeatedly, alternating with or without one of the
built-in 45 alarm tones. The alarm tone notification has an
Supply Voltage 14-30VDc. 90-260VAc output of up to 126dB(A) at 1 metre. The user defined content
Effective Range 300m @ 1KHz can be recorded by either using the on-board microphone or
Measurements 190*184*191mm through the ‘line-in’ audio input using the supplied 3.5mm
audio cable from devices such as a PC, MP3 or CD player.
For multiple unit installations the recording process is only Colours:
required once to create a master unit which can then be used
to program all other A121AX units on the system using the
supplied ‘Synch’ cable, thereby guaranteeing synchronization
during playback.
IP
2,7kg 66 -25º/+55ºC Industry Fire Marine Bell Loudspeaker Buzzer EL Sounder

MV121 Appello-X
The MV121 Appello X is the next generation of user recordable alarm sounder capable of storing up to 2
minutes of content. The MV121 records, stores and plays back with unsurpassed clarity, user defined voice
messages, music or sounds stored directly to non-volatile memory without any intermediate analogue to
01 - INDUSTRY & MARINE AUDIBLE
digital conversion. Low current consumption and CD quality reproduction in a robust fire retardant Type
4/4X/3R/13, IP66/67 housing ensure the MV121 Appello X is suitable for all general signalling applications
including fire, security and process control.
User recordable alarm siren Features
The MV21AX Appello user recordable unit enables the end
Maximum output 126dB(A) @ 1 metre user to record any type of content such as voice or music that
No. of tones 45 (UKOOA / PFEER can then be played back at CD quality output at SPL’s of up
compliant) to 112dB(A) at 1 metre. The user recordable content can be
reproduced repeatedly, alternating with or without one of the
No. of Messages 4 (30 Seconds each) built-in 45 alarm tones. The alarm tone notification has an
Supply Voltage 14-30VDc. 90-260VAc output of up to 126dB(A) at 1 metre. The user defined content
Effective Range 300m @ 1KHz can be recorded by either using the on-board microphone or
Measurements 190*184*191mm through the ‘line-in’ audio input using the supplied 3.5mm
audio cable from devices such as a PC, MP3 or CD player.
For multiple unit installations the recording process is only Colours:
required once to create a master unit which can then be used
to program all other MV121AX units on the system using the
supplied ‘Synch’ cable, thereby guaranteeing synchronization
during playback.
IP
1,2kg 66 -25º/+55ºC Industry Fire Marine Bell Loudspeaker Buzzer EL Sounder LED Xenon
