PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

A100
The A100 is a compact, high output, 104dB(A) alarm sounder. Low current consumption and high SPL in a
robust fire retardant housing ensure the A100 is suitable for all general signalling applications including
fire, security and process control.
Electronic Sounder Features
Maximum output 104dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 32 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 24Vac, 35- • Unit can be mounted using external lugs or
internal BESA compatible fixing positions.
60Vdc, 115Vac, 230Vac • Duplicate cable terminations (in & out for daisy-
Effective Range 32m @ 1KHz chain installations).
Measurements 86*86*76mm • Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Colours:

IP

0,3kg 66 -25º/+55ºC Industry Fire EL Sounder

A105N
The A105N is a high output, 112dB(A) alarm sounder. Low current consumption and high SPL in a robust
fire retardant IP66 housing ensure the A105N is suitable for all general signalling applications including
fire, security and process control.

Electronic Sounder Features
Maximum output 112dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 32 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 24Vac, • Unit can be mounted using external lugs or
35-60Vdc, 72-120Vdc, internal BESA compatible fixing positions.
115Vac, 230Vac • Duplicate cable terminations (in & out for daisy-
Effective Range 60m @ 1KHz chain installations).
Measurements 130*130*133mm • Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Colours:

IP

1,0kg 66 -25º/+55ºC Industry Fire EL Sounder

A112N
The A112N is a high output, 119dB(A) alarm sounder. High SPL in a robust
fire retardant IP66 housing ensure the A112N is suitable for all general signalling applications including
fire,security and process control.
Electronic Sounder Features
Maximum output 119dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 45 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 24Vac, 35- • Unit can be mounted using external lugs or
60Vdc, 90-250Vdc, 115Vac, internal BESA compatible fixing positions.
• Duplicate cable terminations (in & out for daisy-
230Vac
Effective Range 125m @ 1KHz chain installations).
• Tropicalisation available on request.
Measurements 168*168*156mm 01 - INDUSTRY & MARINE AUDIBLE
• Available with custom tone configurations and
frequencies. Colours:

IP

2,1kg 66 -25º/+55ºC Industry Fire EL Sounder
