SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

Bedhead Sounder
The BEDHEAD alarm sounder is a low current consumption device suitable for close proximity signalling in
fire and security applications.
Electronic Sounder
Maximum output 90dB(A) @ 1 metre
No. of tones 10
No. of stages 3
Supply Voltage 10-30Vdc
Effective Range 10m @ 1KHz
Measurements 85*50mm

Colours:

IP

0,3kg 66 -25º/+55ºC Industry EL Sounder

SONF1
The SONF1 is a compact, high output, 100dB(A) alarm sounder. Low current consumption and high SPL
in a robust fire retardant housing ensure the SONF1 is suitable for all general signalling applications
including fire, security and process control.
Electronic Sounder Features
Maximum output 100dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 10 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 2 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 115Vac, 230Vac • Unit can be mounted using external lugs or
Effective Range 30m @ 1KHz internal BESA compatible fixing positions.
Measurements 86*86*56mm • Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Colours:

IP

0,3kg 66 -25º/+55ºC Industry Fire EL Sounder

SONF1HO
The SONF1-HO is a compact, high output, 105dB(A) alarm sounder. Low current consumption and high SPL
in a robust fire retardant housing ensure the SONF1-HO is suitable for all general signalling applications
01 - INDUSTRY & MARINE AUDIBLE
including fire, security and process control.
Electronic Sounder Features
Maximum output 105dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 10 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 2 • Stainless steel fixings.
Supply Voltage 12Vdc, 24Vdc • Unit can be mounted using external lugs or
Effective Range 32m @ 1KHz internal BESA compatible fixing positions.
Measurements 86*86*56mm • Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Colours:
• Reverse polarity diode protection

IP

0,3kg 66 -25º/+55ºC Industry Fire EL Sounder
