PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

HA121
Applications and users that have traditionally demanded conventional electromechanical hooters,
sirens, buzzers and bells can now choose the next generation alternative. The technology employed
in the Hootronic range features the latest in amplifier and digital to analogue conversion technology.
The Hootronic series of products faithfully reproduce the sounds made by legacy electro-mechanical
signalling devices but in a modern, reliable and cost effective way.
Features
Electronic Siren, Buzzer, Hooter & Bell • Automatic synchronisation on multi-sounder
Maximum output 121dB(A) @ 1 metre system.
No. of tones 5 • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 115Vac, 230Vac • Unit can be mounted using external lugs or
Effective Range 300m @ 1KHz internal BESA compatible fixing positions.
Measurements 190*190*191MM • Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request. Colours:

IP

2,7kg 66 -25º/+55ºC Industry EL Sounder Fire Bell Motorsiren Buzzer

HMA121
Applications and users that have traditionally demanded conventional electromechanical hooters,
sirens, buzzers and bells can now choose the next generation alternative. The technology employed
in the Hootronic range features the latest in amplifier and digital to analogue conversion technology.
The Hootronic series of products faithfully reproduce the sounds made by legacy electro-mechanical
signalling devices but in a modern, reliable and cost effective way.
Features
Electronic Siren, Buzzer, Hooter & Bell • Automatic synchronisation on multi-sounder
Maximum output 124dB(A) @ 1 metre system.
No. of tones 5 • Continuously rated.
No. of stages 3 • Large termination area.
Supply Voltage 10-30Vdc, 115Vac, 230Vac • Stainless steel fixings.
Effective Range 300m @ 1KHz • Ratchet adjustable stainless steel ‘U’ bracket
Measurements Ø220*323MM for 360° positioning.
• Duplicate cable terminations(in & out for daisy-
chain installations). Colours:
• Tropicalisation available on request.

IP

3,0kg 66/67 -25º/+55ºC Industry EL Sounder Fire Marine Bell Motorsiren Buzzer

GPH
The GPH series are low profile, high output, 105dB(A) alarm horns designed as a maintenance free,
reliable alternative to solenoid type buzzers. Low current consumption and high SPL in a robust, fire
retardant housing, ensures the GPH is suitable for all general signalling applications.
Alarm Horn - Buzzer Features
Maximum output 105dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 3 system.
No. of stages 1 • Continuously rated.
Supply Voltage 10-30Vdc, 24Vac 115Vac, • Stainless steel fixings.
230Vac • Duplicate cable terminations (in & out for daisy-
Effective Range 32m @ 1KHz chain installations).
Measurements 116*116*30- • Tropicalisation available on request.
152*152*30MM
The GPH1 is a surface mount version with back 01 - INDUSTRY & MARINE AUDIBLE
box, the GPH2 is a flush mount variant for use
in panel mount applications or for use with Colours:
standard 4” back boxes.

IP

0,4kg 54/66 -25º/+55ºC Industry EL Sounder Buzzer
