SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

TDE
The AP Series of air horns are suitable for general purpose signalling where high output is required such
as foundries, steelworks and petrochemical plants. Operated from a compressed air supply, their powerful
low frequency sound cuts through background noise to provide an effective alarm. Optional compressor is
available for applications which do not have an on-site air supply.
Air Horn Features
Maximum output 125dB(A) @ 1 metre • Continuous signal
No. of tones 1 • Optional compressor if no direct air supply
No. of stages 55-140 Psi available
Supply Voltage 24Vdc / 230Vdc • Robust construction
Effective Range 300+m • Optional solenoid valve available with 24Vdc or
Measurements Ø203*85mm 230Vac supply

Colours:

IP

1,4kg 66 -30º/+90ºC Industry Fire Airhorn

AQUA
Aqua 30 is a completely sealed loudspeaker designed for underwater applications. The Aqua 30
features rated power 30 watts at 8 ohms and is constructed from ABS materials. The Aqua 30 is ideal
for applications including synchronised swimming, diving courses, hotels, leisure parks and special
applications such as test laboratories.
PA Underwater Loadspeaker Features
Maximum output 118dB(A) @ 1 metre • Cable termination code: Green/yellow: Ground
No. of tones 80 – 20.000 Hz Brown: (+). Blue: (-)
No. of stages 20 W / 30 W • Recommended installation deep 0,5m to 2m.
Supply Voltage (-6dB) 1kHz / 4kHz: 180° • Warning, this loudspeaker generates very high
/ 180° sound pressures even when driven at low power.
Effective Range 200m2 • For optimum performance, always use the
Measurements 103*137*53mm correct voltage / power and operate within the
frequency limits as stated.
• Do not open loudspeaker when energized.
• This loudspeaker is supplied with a 2 year Colours:
warranty against defective workmanship.

IP

2,2kg 68 -20º/+90ºC Subsea Loudspeaker

ML15
The ML15 15W PA loudspeaker features a robust, fire retardant, IP66 & IP67 housing; suitable for harsh
environments with high ambient noise levels.
01 - INDUSTRY & MARINE AUDIBLE
PA Horn Loudspeaker Features
SPL 108dB +/-3dB @ 1w @ 1m • Continuously rated.
- Pink noise 118dB +/-3dB • Large termination area.
@ 15w (rated power) @ 1m • Stainless steel fixings.
Rated power 15 Watts RMS • Ratchet adjustable stainless steel ‘U’ bracket
Dispersion 120° @ 1kHz & 32° @ 4kH for 360° positioning.
Frequency range 400Hz to 8000 Hz • Duplicate cable terminations (in & out for daisy-
Impedence/ line 8/16 Ohm or 70v/100v Line chain installations).
Measurements Ø181*273MM • Tropicalisation available on request.

Colours:

IP

2,6kg 66/67 -25º/+55ºC Industry Marine Loudspeaker
