PRODUCT                                                         PRODUCT                   AVAILABLE      SIGNALLING
      INFORMATION                                                          IMAGE                    COLOURS        SIGNALLING


        ML25
        The ML15 15W PA loudspeaker features a robust, fire retardant, IP66 & IP67 housing; suitable for harsh
        environments with high ambient noise levels.
         PA Horn Loudspeaker                Features
         SPL             111dB +/-3dB @ 1w @ 1m   • Continuously rated.
                         - Pink noise       • Large termination area.
                         121dB +/-3dB @ 25w   • Stainless steel fixings.
                         (rated power) @ 1m  • Ratchet adjustable stainless steel ‘U’ bracket
         Rated power     25 Watts RMS       for 360° positioning.
         Dispersion      120° @ 1kHz & 32° @ 4kH  • Duplicate cable terminations (in & out for daisy-
         Frequency range  400Hz to 8000 Hz    chain installations).
         Impedence/line   8/16 Ohm or 70v/100v Line  • Tropicalisation available on request.
         Measurements    Ø220*323MM

                                                                                                    Colours:




               IP

          2,6kg  66/67  -25º/+55ºC  Industry  Marine  Loudspeaker
