SIGNALLING
SIGNALLING INFORMATION PRODUCT AVAILABLE
PRODUCT
COLOURS
114 Buzzer
The 114 range consists of continuous tone panel mounted piezo buzzers.. Quick-connect blades for push-
on or direct solder attachment.
Ø30,5mm Buzzers - Panel Mount Indicators
Maximum output 85dB(A) @ 1 metre
No. of tones 1
No. of stages 1
Supply Voltage 12-30Vdc/ac, 110-240Vac/
dc
Effective Range 10m @ 1KHz
Measurements Ø30,5mm
Colours:
IP
0,1kg 30 -20º/+60ºC Industry Buzzer
DS5
The sounders from the DS 5 series can be used for tough demands under industrial conditions and as
universal alarms. The sounders, which are suitable for use both indoors and outdoors, generate warning
signals in 31 different tones can be selected with the aid of an internal switch.
Electronic Sounder Features
Maximum output 105dB(A) @ 1 metre • Die-cast aluminium body.
No. of tones 32 (UKOOA / PFEER • Stainless steel fixings.
compliant) • Duplicate cable terminations (in & out for daisy-
No. of stages 3 chain installations).
Supply Voltage 12Vdc, 24Vdc, 24Vac,
48Vdc, 115Vac, 230Vac
Effective Range 60m @ 1KHz
Measurements 130*130*133mm
Colours:
IP
2,15kg 66/67 -40º/+55ºC Industry Fire Marine EL Sounder
DS10
The sounders from the DS 10 series can be used for tough demands under industrial conditions and as
universal alarms. The sounders, which are suitable for use both indoors and outdoors, generate warning
01 - INDUSTRY & MARINE AUDIBLE
signals in 31 different tones can be selected with the aid of an internal switch.
Electronic Sounder Features
Maximum output 110dB(A) @ 1 metre • Die-cast aluminium body.
No. of tones 32 (UKOOA / PFEER • Stainless steel fixings.
compliant) • Duplicate cable terminations (in & out for daisy-
No. of stages 3 (Total of 16 seconds) chain installations).
Supply Voltage 12Vdc, 24Vdc, 24Vac,-
48Vdc, 115Vac, 230Vac
Effective Range 60m @ 1KHz
Measurements 130*130*133mm
Colours:
IP
2,15kg 66/67 -40º/+55ºC Industry Fire Marine EL Sounder
