PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

E2S22D
The E2S-22D range consists of the highest quality FloydBell continuous tone and dual tone panel
mounted piezo buzzers. The built-in volume control provides variable attenuation up to 20dB(A). The
terminals are standard 6.35mm/0.25” quick-connect blades for push-on or direct solder attachment.
ø22mm Buzzers - Panel Mount Indicators Features
Maximum output 95dB(A) @ 1 metre • Volume control.
• Stainless steel diaphragm.
No. of tones 2
No. of stages 1 • Withstands vibration between 0 and 55 Hz. on
all axes.
Supply Voltage 10-30Vdc, 115Vac, 230Vac
Effective Range 10m @ 1KHz
Measurements Ø22mm

Colours:

IP

0,1kg 65 -20º/+65ºC Industry Buzzer

E2S28D
The E2S-22D range consists of the highest quality FloydBell continuous tone and dual tone panel
mounted piezo buzzers. The built-in volume control provides variable attenuation up to 20dB(A). The
terminals are standard 6.35mm/0.25” quick-connect blades for push-on or direct solder attachment.

ø28mm Buzzers - Panel Mount Indicators Features
Maximum output 95dB(A) @ 1 metre • Volume control.
No. of tones 2 • Stainless steel diaphragm.
No. of stages 1 • Withstands vibration between 0 and 55 Hz. on
Supply Voltage 10-30Vdc, 115Vac, 230Vac all axes.
Effective Range 10m @ 1KHz
Measurements Ø28mm

Colours:

IP

0,1kg 65 -20º/+65ºC Industry Buzzer

118 & 119 Buzzers
The 118 & 119 range consists of continuous tone and dual tone panel mounted piezo buzzers. The
Optional dust cover will provide extra protection against harsh environments. Quick-connect blades for
push-on or direct solder attachment.
ø28mm Buzzers - Panel Mount Indicators Features
Maximum output 90dB(A) @ 1 metre • Stainless steel diaphragm.
No. of tones 1
No. of stages 1
Supply Voltage 12Vdc/ac, 24Vdc/ac,
48Vdc/ac, 115Vac, 230Vac
Effective Range 10m @ 1KHz
Measurements Ø28mm 01 - INDUSTRY & MARINE AUDIBLE

Colours:

IP

0,1kg 30/43 -20º/+60ºC Industry Buzzer
