PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

B300SND
The B300SND is a compact signalling horn suitable for mounting on machinery or in general signalling
applications. The B300SND reproduces the alert sound of traditional electro-mechanical equivalents but
without any of the reliability issues. In addition to the ‘buzzer’ type sound the unit features a further two
alarm sounds.
Electronic Sounder Features
Maximum output 98dB(A) @ 1 metre • Bayonet fixing body.
No. of tones 3 • Anti-tamper locking screw.
No. of stages 1 • Stainless steel fixings.
Supply Voltage 10-30Vdc/ac, 40-260Vac/ • Compatible with B350 and B450 traffic light
dc series.
Effective Range 10m @ 1KHz
Measurements Ø100*103MM

Colours:

IP

1,0kg 65 -25º/+50ºC Industry EL Sounder

B400SND
The B400SND is a 110 dB(A) high output signalling horn suitable for a variety of general signalling
applications. The B400SND reproduces the alert sound of traditional electro-mechanical equivalents but
without any of the reliability issues. In addition to the ‘buzzer’ type sound the unit features a further two
alarm sounds. All first stage sounds have a remotely selectable second stage.
Features
Electronic Sounder • Bayonet fixing body.
Maximum output 110dB(A) @ 1 metre
No. of tones 3 • Anti-tamper locking screw.
• Stainless steel fixings.
No. of stages 2 • Compatible with B350 and B450 traffic light
Supply Voltage 10-30Vdc/ac, 40-260Vac/ series
dc
Effective Range 60m @ 1KHz
Measurements Ø140*120MM
Colours:

IP

1,0kg 65 -25º/+50ºC Industry EL Sounder

H100B
The H100 series contains two variants of signalling horn, the H100T with trumpet horn and the compact
H100B without trumpet horn. Both electronic signals authentically reproduce the alert sound of
traditional electro-mechanical units but without any of the reliability issues.
Electronic Sounder Features
Maximum output 100dB(A) @ 1 metre • Volume control
• Stainless steel fixings.
No. of tones 3
No. of stages 1 Rated for continuous use the H100 series is a
Supply Voltage 10-30Vdc/ac, 40-260Vac/ compact, high output signal suitable for a variety
dc of installation types. In addition to the ‘buzzer’
Effective Range 30m @ 1KHz type sound the unit features a further two alarm
Measurements Ø85*80MM sounds. 01 - INDUSTRY & MARINE AUDIBLE

Colours:

IP

0,1kg 65 -25º/+50ºC Industry EL Sounder
