SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

A121
The A121 is a very high output, 126dB(A) alarm sounder. High SPL in a robust, fire retardant IP66 housing
ensure the A121 is suitable for all general signalling applications including fire, security and process
control.
Electronic Sounder Features
Maximum output 126dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 45 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 24Vac, 35- • Unit can be mounted using external lugs or
60Vdc, 90-250Vdc, 115Vac, internal BESA compatible fixing positions.
230Vac • Duplicate cable terminations (in & out for daisy-
Effective Range 300m @ 1KHz chain installations).
Measurements 190*190*192mm • Tropicalisation available on request.
• Available with custom tone configurations and
frequencies. Colours:

IP

2,7kg 66 -25º/+55ºC Industry Fire EL Sounder

MA112
The MA112 is a high output, 119dB(A) alarm sounder. With a robust, fire retardant, IP66 & IP67 housing,
the MA112 is particularly suitable for harsh environments with high ambient noise levels.
Electronic Marine Sounder Features
Maximum output 119dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 45 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 24Vac, 35- • Ratchet adjustable stainless steel ‘U’ bracket
60Vdc, 115Vac, 230Vac for 360° positioning
Effective Range 125m @ 1KHz • Duplicate cable terminations (in & out for daisy-
Measurements Ø181*273MM chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations and
frequencies.
Colours:

IP

3,0kg 66/67 -25º/+55ºC Industry Fire Marine EL Sounder

MA121
The MA121 is a very high output, 126dB(A) alarm sounder. With a high SPL in a robust, fire retardant IP66
& IP67 housing, the MA121 is particularly suitable for harsh environments with high ambient noise levels.
01 - INDUSTRY & MARINE AUDIBLE
Electronic Marine Sounder Features
Maximum output 126dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
No. of tones 45 (UKOOA / PFEER system.
compliant) • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 24Vac, 35- • Ratchet adjustable stainless steel ‘U’ bracket
60Vdc, 115Vac, 230Vac for 360° positioning
Effective Range 300m @ 1KHz • Duplicate cable terminations (in & out for daisy-
Measurements Ø220*323MM chain installations).
• Tropicalisation available on request.
• Available with custom tone configurations and
frequencies.
Colours:

IP

3,0kg 66/67 -25º/+55ºC Industry Fire Marine EL Sounder
