SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

H100T
The H100 series contains two variants of signalling horn, the H100T with trumpet horn and the compact
H100B without trumpet horn. Both electronic signals authentically reproduce the alert sound of
traditional electro-mechanical units but without any of the reliability issues.
Signalling Horn with Trumpet Features
Maximum output 100dB(A) @ 1 metre • Volume control
No. of tones 3 • Stainless steel fixings.
No. of stages 1
Supply Voltage 10-30Vdc/ac, 40-260Vac/ Rated for continuous use the H100 series is a
dc compact, high output signal suitable for a variety
Effective Range 30m @ 1KHz of installation types. In addition to the ‘buzzer’
Measurements Ø85*80MM type sound the unit features a further two alarm
sounds.

Colours:

IP

0,1kg 65 -25º/+50ºC Industry EL Sounder

H110T
The H110T is a very high output electronic signal horn capable of generating a traditional ‘buzzer’ warning
tone traditionally associated with electro-mechanical signals.
Signalling Horn with Trumpet Features
Maximum output 110dB(A) @ 1 metre • Volume control
No. of tones 3 • Stainless steel fixings.
No. of stages 2
Supply Voltage 10-30Vdc/ac, 40-260Vac/ With an output of 110dB(A) the H110T is ideal for
dc all general signalling applications and the ingress
Effective Range 30m @ 1KHz protection ratingof IP65 means it is suitable for
Measurements Ø112*336MM indoor and outdoor installations.
In addition to the ‘buzzer’ type sound the unit
features a further two alarm tones. The first stage
sounds also have a remotely selectable second
stage. Colours:

IP

0,35kg 65 -25º/+50ºC Industry EL Sounder

HA105
Applications and users that have traditionally demanded conventional electromechanical hooters,
sirens, buzzers and bells can now choose the next generation alternative. The technology employed
01 - INDUSTRY & MARINE AUDIBLE
in the Hootronic range features the latest in amplifier and digital to analogue conversion technology.
The Hootronic series of products faithfully reproduce the sounds made by legacy electro-mechanical
signalling devices butin a modern, reliable and cost effective way.
Features
Electronic Siren, Buzzer, Hooter & Bell
Maximum output 112dB(A) @ 1 metre • Automatic synchronisation on multi-sounder
system.
No. of tones 5 • Continuously rated.
No. of stages 3 • Stainless steel fixings.
Supply Voltage 10-30Vdc, 115Vac, 230Vac • Unit can be mounted using external lugs or
Effective Range 60m @ 1KHz internal BESA compatible fixing positions.
Measurements 130*130*133MM • Duplicate cable terminations (in & out for daisy-
chain installations).
• Tropicalisation available on request. Colours:
Remote switch generates genuine ‘tail off’ to
sound when alarm is terminated.

IP

1,0kg 66 -25º/+55ºC Industry Fire EL Sounder Bell Motorsiren Buzzer
