PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

B200
The B200 Series is comprised of a Xenon strobe beacon, permanent filament bulb, blinking filament bulb
and a permanent LED array beacon version. The surface mount base can also be supplied with a right
angle bracket or with a pole mounted assembly.
Panel Mount Beacon Features
Supply Voltage Xenon 10-30Vdc, 115Vac, 230Vac • Bayonet fixing lens.
Supply Voltage LED 10-30V dc/ac, 90-230Vac • Anti-tamper locking screw.
Supply Voltage Filament 12Vdc, 24Vdc, 48Vdc, • Stainless steel fixings
115vAC, 230Vac
Lens type Prismatic (standard) or Wall bracket and pole mount bracket available.
plain
Measurements Ø60x80mm

Lens colours:

Housing colours:
IP

0,1kg 65 -25º/+50ºC Industry Xenon LED Filament

B300
The B300 series is comprised of a Xenon strobe beacon, permanent filament bulb or halogen beacon,
blinking filament bulb or halogen beacon, rotating beacon and a multi-function LED array beacon. The
surface mount base can also be supplied with a right angle bracket or with a pole mounted surface.

Beacon Features
Supply Voltage Xenon 12Vdc/ac, 24Vdc/ac, • Bayonet fixing lens.
48Vdc/ac, 115Vac, 230Vac • Anti-tamper locking screw.
Supply Voltage LED 10-50Vdc, 90-230Vac • Stainless steel fixings
Supply Voltage Filament 12Vdc, 24Vdc, 48Vdc, • Total of 9 user selectable operation modes:
115Vac, 230Vac - 4 rotating configurations
Supply Voltage Halogen 12Vdc, 24Vdc, 115Vac, - 4 flashing configurations
230Vac - Steady mode for status applications
Lens type Prismatic or plain • The multi-voltage DC unit also features a
Measurements Ø100x150mm remotely
• Selectable 2nd stage flash pattern.
Lens colours:
Wall bracket and pole mount bracket available

Housing colours:

IP

0,1kg 65 -25º/+50ºC Industry RPM 180 Xenon LED Filament Halogen

B400
The series is comprised of a Xenon strobe beacon, permanent filament bulb or halogen beacon, blinking
filament bulb or halogen beacon, rotating beacon and a multi-function LED array beacon. The surface
mount base can also be supplied with a right angle bracket or with a pole mounted surface.
Beacon Features
Supply Voltage Xenon 24Vdc/ac, 48Vdc/ac, • Bayonet fixing lens.
115Vac, 230Vac • Anti-tamper locking screw.
Supply Voltage LED 10-50Vdc, 115Vac, 230Vac • Stainless steel fixings
Supply Voltage Filament 24Vdc, 115Vac, 230Vac • Total of 9 user selectable operation modes:
Supply Voltage Halogen 12Vdc, 24Vdc, 115Vac, - 4 rotating configurations
230Vac - 4 flashing configurations
Lens type Prismatic (standard) or - Steady mode for status applications
plain • The multi-voltage DC unit also features a
Supply Voltage Filament Ø140x220mm remotely selectable 2nd stage flash pattern. 01 - INDUSTRY & MARINE VISUAL
Also available as synchronized units. Lens colours:
Wall bracket and pole mount bracket available.
Housing colours:

IP

0,5kg 65 -25º/+50ºC Industry RPM 180 Xenon LED Filament Halogen
