SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

PMF
The PMF Series gives extreme light outputs of up to 30Joules.
reliable performance even under the toughest working and production conditions, e.g. possible voltage
fluctuations, highambient temperatures up to + 55 °C, high relative humidity up to 90 %.
Beacon Features
Supply Voltage Xenon 24Vdc, 230Vac • Mounting-friendly; large variety of mounting
Measurements Ø177*170 mm methods
• Very good perceptibility over great distances;
low power consumption
• Mounting-friendly; large variety of mounting
methods
Secure 360° alarm for large distances (indoors or
outdoors)

Lens colours:

Housing colours:
IP

0,8kg 65 -40º/+55ºC Industry Fire Xenon

E-Flare
The E-flare Portable LED beacon offer a simple signalling solution by creating a highly visible RED warning
signal which does not require hardwiring and which is operated by two D cell batteries (not included)
which give over 40 hours life.

Portable Beacon Features
Supply Voltage 2 x 1,5v D cell batteries • 40 hours of peak brightness operation on 1 set
Measurements Ø60*200 mm of batteries
• Shock resistant
• Versatile accessory options
Suitable for a wide range of applications the
E-flare beacon has been designed with versatility
in mind.

Lens colours:

Housing colours:

IP

0,2kg 66 -20º/+50ºC Industry Fire Automotive Portable LED

Pilot lights
The E2S-22D range includes buzzers, combination units and pilot lights featuring super bright multichip
LEDs. Ingress protection to IP65, low current consumption and unsurpassed reliability under extreme
conditions are all standard features of the E2S-22D range.
01 - INDUSTRY & MARINE VISUAL
Pilot light The range utilises screw terminals with wire
Supply Voltage 24Vdc/ac, 48Vdc/ac, 110- guards for ease of installation and the ability to
130Vac/dc, 230Vac daisy chain the lights into an array.
Measurements Ø22*50 mm

Lens colours:

Housing colours:

IP

0,1kg 65 -20º/+50ºC Industry LED
