SIGNALLING
SIGNALLING INFORMATION PRODUCT AVAILABLE
PRODUCT
COLOURS
B350 Traffic Light
The B350 series of traffic light beacons are available in single E14 filament bulb or high output L.E.Darray
versions. The compact housing is ideal for space constrained applications or for mounting directly onto
machinery.
Traffic Light Beacon Features
Supply Voltage LED 10-30Vdc, 90-230V ac 50/ • Bayonet fixing lens.
60Hz • Anti-tamper locking screw.
Supply Voltage Filament 12-250V • Stainless steel fixings.
Measurements Ø100x140mm • L.E.D. unit is supplied with a clear prismatic lens
to optimize visibility
In applications with high ambient light levels.
Mounting brackets for single and multiple units
available.
Lens colours:
IP
0,35kg 65 -25º/+50ºC Industry Traffic LED Filament
B450 Traffic light
The B450 series of traffic light beacons are available in single E27 filament lamp, dual E14 filament lamp
or high output L.E.D array versions.
Marine Light Beacon Features
Supply Voltage LED 10-30Vdc, 90-230V ac 50 • Bayonet fixing lens.
/ 60Hz • Anti-tamper locking screw.
Supply Voltage Filament 12-250V • Stainless steel fixings.
Measurements ø140*177mm • L.E.D. unit is supplied with a clear prismatic lens
to optimize visibility
In applications with high ambient light levels.
Lens colours:
IP
0,35kg 65 -25º/+50ºC Industry Traffic LED Filament
MB Marine Beacons
The MB Series is a beacon featuring a robust, fire retardant, IP66 & 67 housing; suitable for harsh
environments.
01 - INDUSTRY & MARINE VISUAL
Marine Beacons Features
Supply Voltage Xenon 12Vdc, 24Vdc, 48Vdc, • Continuously rated
115Vac, 230Vac • Large termination area
Supply Voltage LED 10-50Vdc, 24Vac, 115Vac, • Stainless steel fixings
230vac • Ratchet adjustable U bracket for 360°
Measurements ø170*230mm positioning
Lens colours:
Housing colours:
IP
0,35kg 65 -25º/+50ºC Industry Marine LED Xenon
