PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

STB
The STB2, STB3 and STB4 are customisable visual signals featuring a tower of 2, 3 or 4 AlertAlight L101
type beacons.
Light column Features
Supply Voltage Xenon 12Vdc/ac, 24Vdc/ac, Each beacon position can contain either a Xenon
48Vdc, 115Vac, 230Vac or high output L.E.D. light source.
Supply Voltage LED 12Vdc, 24Vdc, 48Vdc,
115Vac, 230vac The STB2, STB3 or STB4 Assembly features a
Measurements 86 x 86 x 83 mm (each pre-wired junction box and cable loom enabling
unit) the end user to determine beacon type and
position during installation.
Also available as telephone initiated and
synchronized units
*Not available in LED
Lens colours:

Housing colours:
IP

0,35kg 65 -25º/+50ºC Industry Traffic Junction Box LED Xenon

ITS
Can be customised on request, and be delivered with sounders and beacons on demand. Available with up
to 8 sources, lamp test &control unit.
Light column
Supply Voltage 12Vdc, 24Vdc, 48Vdc,
115Vac, 230Vac

Lens colours:

Housing colours:
Other colours available
on request.
IP
2-10kg 66 -25º/+50ºC Industry Fire Telephone Junction Box LED Filament

Kombisign
The kombisign range allows a completely free combination of optical and adible signal elements.
Light column Features
Supply Voltage Xenon 24Vdc/ac, 115Vac, 230Vac Also available with sound units, GSM alarm, an a
wide range of mounting brackets.
Can be delivered with a customized indication
board.

Lens colours: 01 - INDUSTRY & MARINE VISUAL

Housing colours:
IP

2-10kg 66 -25º/+50ºC Industry Fire Traffic Telephone Junction Box LED Filament Xenon
