SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

EHS
Rotating mirror beacon in painted mild steel housing, for less aggressive environments. Quite enduring
with low noise friction-gear. Not suited for outdoor use and/or temperatures below freezing point.
Rotating Beacon Should be mounted preferably in upright position.
Supply Voltage LED 12Vdc, 24Vdc, 115Vac,
230Vac NB: Mounting in horizontal position will increase
Measurements Ø148 x 215 mm were & tear on motor, ball bearings and gear, and
may cause over heating and meltdown.

Lens colours:

Housing colours:
IP

1,1kg 54 -10º/+50ºC Industry Fire RPM 180 Filament Halogen

WBS/WBL
Sturdy anodized aluminum makes these units able to handle harsh environments. With the shock proof
lens these are well suited to be used in industrial environments.
Beacon, 5 Joule Features
Supply Voltage WBL 24Vac, 42Vac, 48Vac, • Back boxes available with and without mounting
110Vac, 230Vac lugs
Supply Voltage WBS 12Vdc, 24Vdc, 48Vdc, • Tropicalisation available on request
60Vdc, 80Vdc, 110Vdc • Can be stacked to create multi-signal units
Measurements Ø54*200 mm • Can be combined with alertalarm & Sonora
audible signals
Also available as telephone initiated and
synchronized units
*Not available in LED
Lens colours:

Housing colours:

IP

0,3kg 54 -40º/+55ºC Industry Fire Xenon

ABS/ABL
Sturdy anodized aluminum makes these units able to handle harsh environments. With the shock proof
lens these are well suited to be used in industrial environments.
Beacon,15 Joule Features
01 - INDUSTRY & MARINE VISUAL
Supply Voltage ABL 24Vac, 42Vac, 48Vac, • Bayonet fixing lens.
110Vac, 230Vac • Anti-tamper locking screw.
Supply Voltage ABS 12Vdc, 24Vdc, 48Vdc, • Stainless steel fixings
60Vdc, 80Vdc, 110Vdc
Measurements Ø80*242 mm

Lens colours:

Housing colours:

IP

0,3kg 54 -40º/+55ºC Industry Fire Xenon
