PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

PB/PD 2005/2010
A classic flashing light for indoors and outdoors.
Beacon, 5/10 Joule High angled pyramided lens secures good visibility
Supply Voltage PB2005 12Vdc/ac, 24Vdc/ac, from all angels.
48Vdc/ac, 60Vdc, 80Vdc,
110Vac, 127Vac, 230Vac
Supply Voltage WBS 12Vdc, 24Vdc, 36Vdc,
42Vac, 48Vdc, 60Vdc,
80Vdc, 110Vac, 230Vac
Measurements 111*166*127mm

Lens colours:

Housing colours:
IP

1,30kg 66 -25º/+55ºC Industry Fire Filament Xenon

Quadro
Extraordinary housing protection (IP 66, IK 08 and UV-protected PC housing) and innovative LED
technology provide for very bright signals, long service lives and reliable operation.
Beacon Also available as traffic lights.
Supply Voltage Xenon 18-30Vdc, 95-120Vac,
195-253Vac
Supply Voltage LED 10-60Vac/dc, 95-253Vac
Measurements 130*130*130mm

Lens colours:

Housing colours:

IP

1,3kg 66 -25º/+55ºC Industry Fire Traffic LED Xenon

X401
X401/400 Series provides a 360degree light ouput and has a Single Flash or Double Flash option. The
Double Flash option extends the signal duration making it more noticeable to the humaneye. Brightness is
increased by the use of a Dioptric (Fresnel) lens which magnifies the light output.
Beacon Features
Supply Voltage Xenon 12Vdc, 24Vdc, 48Vac, • Continuously rates
115Vac, 230Vac • Suitable for surface or wall mounting
Measurements Ø150*205 mm • Single or double flash option
• Diode polarised (DP) options available for fire
alarm systems.
The X401/400 DIN Base Series utilises a
discharge capacitor and converter circuit to ignite
xenon gas inside a tube, resulting with a flash of
light. 01 - INDUSTRY & MARINE VISUAL
Lens colours:

Housing colours:
IP

1,3kg 66 -25º/+55ºC Industry Fire RPM 180 Xenon
