Fittings

1
Heavy-duty pressure clamps Hose connection with clamp nut 1
for RUBBER HOSES and spring guard
2
Heavy-duty
For For clamp 1 Clamp nut, brass
TURBO RUBAIR mm Ordering No.
– – 22.0-25.0 9000 0194 00
20 16 25.0-28.0 9000 0195 00
– 20 29.0-32.0 9000 0196 00 Hose diameter
– 25 34.0-38.0 9000 0197 00 Outside/Inside Male thread
mm in Ordering No.
10/8 1/4 BSP 9721 4002 89
10/8 3/8 BSP 9721 4002 90
12/9 1/4 BSP 9721 4000 86
Bushing 12/10 3/8 BSP 9721 4000 88
Male thread – female thread 15/12.5 1/2 BSP 9721 4000 89
Male threaded hose nipple with clamp nut should be used with female threaded
quick couplings.
Male Female
thread thread
in in Ordering No.
2 Spring guard in steel
1/4 BSP 1/8 BSP 9090 0799 00
3/8 BSP 1/4 BSP 9090 0798 00
1/2 BSP 1/4 BSP 9090 1469 00
1/2 BSP 3/8 BSP 9090 0797 00 Hose diameter
3/4 BSP 1/2 BSP 9090 0796 00 Outside/Inside
1 BSPT 3/4 BSP 9090 0795 00 mm Ordering No.
10/8 9721 4002 88
12/10 9721 4000 91
15/12 9721 4002 85
The spring guard should be used with the clamp nut above.
Double connection
Male taper thread – male taper thread

From To
thread thread
in in Ordering No. Manifolds
1/8 BSPT 1/8 BSPT 9090 0100 00 3/8 inlet on each side, 1/4 outlets for
1/8 BSPT 1/4 BSPT 9090 0110 00 couplings
1/4 BSPT 1/4 BSPT 9090 0120 00
1/4 BSPT 3/8 BSPT 9090 0130 00
3/8 BSPT 3/8 BSPT 9090 0140 00
3/8 BSPT 1/2 BSPT 9090 0150 00 Thread Number
1/2 BSPT 1/2 BSPT 9090 0160 00 Inlet Outlet of
1/2 BSPT 3/4 BSPT 9090 0170 00 in in outlets Ordering No.
3/4 BSPT 3/4 BSPT 9090 0180 00 3/8 BSP 1/4 BSP 4 9090 0201 00
3/4 BSPT 1 BSPT 9090 0190 00 3/8 BSP 1/4 BSP 5 9090 0201 01
1 BSPT 1 BSPT 9090 0200 00 3/8 BSP 1/4 BSP 6 9090 0201 02

Manifolds
Double adjustable connection 3/8 inlet on each side, 1/4 outlet on
Male thread – male thread both sides for couplings

From To
thread thread Thread Number
in in Ordering No. Inlet Outlet of
1/2 BSP 1/2 BSP 9090 0806 00 in in outlets Ordering No.
3/8 BSP 1/4 BSP 4 9090 0201 10
3/8 BSP 1/4 BSP 6 9090 0201 11
3/8 BSP 1/4 BSP 8 9090 0201 12
3/8 BSP 1/4 BSP 10 9090 0201 13
Sealing rings for double adjustable
connection

Spare rubber
For coupling sealing ring for
with male thread adjustable connections
in Ordering No.
1/2 BSP 9090 0884 00
1 BSP 9090 0886 00
144 Air line installation
