Accessories

See
illustra-
Accessories Straight Grinders GTR 40 LSR 28 UNF 3/8'' LSR 28 UNC 1/2'' LSR 43 LSR 48 UNC 1/2'' LSR 48 UNC 5/8'' LSR 64 tion
Flange nut 4150 0670 00 4150 1269 01 4150 1269 02 4150 0776 00 4150 0776 00 4150 0670 00 4150 0670 00 3
Front washer 4150 0671 00 4150 1270 01 4150 1270 02 4150 0731 00 4150 0731 00 4150 0671 00 4150 0671 00 4
Locking kit 4170 1188 90 - - - - - -
Rear flange for 0-25x13 mm wheel (WxH) - - - 4150 0732 00 - - - 1
Rear flange for 0-25x16 mm wheel (WxH) - - - - 4150 0732 01 - - 1
Rear flange for 25x16 mm wheel (WxH) - - - - 4150 0732 02 - - 1
Rear flange for 25x20 mm wheel (WxH) - - - 4150 0881 00 4150 0732 03 - - 1
Rear flange for 25x25 mm wheel (WxH) - - - - 4150 0732 04 - - 1
Rear flange for 13x10 mm wheel (WxH) 4150 1268 01 - - - - - 1
Rear flange for 13x20 mm wheel (WxH) - - 4150 1271 01 - - - - 1
Rear flange for 20-25x16 mm wheel (WxH) 4150 0619 00 - - - - 4150 0619 00 4150 0619 00 1
Rear flange for 20-25x20 mm wheel (WxH) 4150 1650 00 - - - - 4150 1650 00 - 1
Rear flange for 20-25x25 mm wheel (WxH) 4150 0713 00 - - - - 4150 0713 00 - 1
Rear flange for 20-25x32 mm wheel (WxH) 4150 0620 00 - - - - 4150 0620 00 4150 0620 00 1
Spacer for cone wheel 4150 0787 00 - - - - 4150 0787 00 4150 0787 00 2
Steel wire brush Ø115 mm for 5/8" spindle - - - - - - 4170 0491 00
Attachment set for Ø115 mm wire brush - - - - - - 4170 0459 81

MultiFlex 8202 1350 60 8202 1350 60 8202 1350 60 8202 1350 60 8202 1350 60 8202 1350 60 8202 1350 60 5

5

1
4
3
2

Productivity Kits

Air inlet Economical
Model BSP air flow Max hose, 5 m Coupling Lubrication Ordering No.
MIDI Optimizer F/RD EQ10-R13-W, incl. whip hose 3/8” 21 l/s Rubair 13 mm ErgoQIC 10 Yes 8202 0850 14
MIDI Optimizer F/RD EQ10-R13-W, incl. whip hose - 21 l/s Rubair 13 mm ErgoQIC 10 Yes 8202 0850 15
MIDI Optimizer F/RD EQ10-T13 3/8” 21 l/s Turbo 13 mm ErgoQIC 10 Yes 8202 0850 17
MIDI Optimizer F/R EQ10-T13 1/2” 21 l/s Turbo 13 mm ErgoQIC 10 No 8202 0850 04
MIDI Optimizer F/RD EQ10-T13 1/2” 21 l/s Turbo 13 mm ErgoQIC 10 Yes 8202 0850 13
MIDI Optimizer F/RD EQ10-T16 1/2” 31 l/s Turbo 16 mm ErgoQIC 10 Yes 8202 0850 12
MAXI F/R C-T16 1/2” 43 l/s Turbo 16 mm Claw No 8202 0850 05
MAXI F/RD C-T20 1/2” 75 l/s Turbo 20 mm Claw Yes 8202 0850 20

Material removal tools 25
