Accessories

Accessories Grinders LSV19 LSV28 LSV38 LSS53 See illustration
Flange depressed center wheel kit - - - 4170 0219 87 2a
Flange cut-off wheel kit - - - 4170 1133 87 2b
Flange cup wheel kit (dia 125mm, incl. wheel guard) - - - 4170 0664 80 3
Flange nut - 4150 1160 02 4170 0758 01 -
Flange nut kit 4150 1158 80 4150 1160 80 - - -
Flange nut, quick change Fixtec - M14 - - 4150 1929 00 - -
Adapter for fitting flexible depressed center wheel (for LSV28 S060-18) - 4170 0759 00 - - 2
Support handle - 4175 0868 80 4175 0868 80 - -
Vibration damped handle 4150 1521 80 4150 1521 80 - -

Diamond cutting wheels
Ø 100 mm - 3780 5074 00 - - -
Ø 125 mm - - 3780 5074 61 - -
Ø 180 mm - - - 3780 5074 62 -
Spot suction kit for Diamond cutting wheel
Ø 125 mm (cutting depth 30 mm) - - 3780 4008 74* - -

Spot suction kit for depressed center wheel
Ø 125 mm wheel kit - 3780 4008 70 3780 4008 73* - 1
Adapter UNF 3/8'' UNC 5/8'' (incl. in kit) - 4021 0457 00 - - -
Nut 5/8'' (incl. in kit) - 3780 2722 00 - - -

Add on spot suction
Ø 115-125 mm - 3780 4032 14 3780 4032 14 - -
Ø 180-230 mm - - - 3780 4032 12 -
Alu-cut guard kit - - 4112 1166 90 - -
Saw blade, Ø 125 mm for cutting applications, 30 teeth, 2 mm thick - - 4112 1164 00 - -
Saw blade, Ø 125 mm for milling applications, 6 teeth, 4 mm thick - - 4112 1162 00 - -
MultiFlex 8202 1350 20 8202 1350 22 8202 1350 24 8202 1350 60 5
*Only for LSV38 D120, 8423 0800 02

3
2

2a 2b
1
5

Productivity Kits

Air inlet Economical
Model BSP air flow Max hose, 5 m Coupling Lubrication Ordering No.
MIDI Optimizer F/RD EQ10-R13-W, incl. whip hose 3/8'' 21 l/s Rubair 13 mm ErgoQIC 10 Yes 8202 0850 14
MIDI Optimizer F/RD EQ10-R13-W, incl. whip hose – 21 l/s Rubair 13 mm ErgoQIC 10 Yes 8202 0850 15
MIDI Optimizer F/RD EQ10-T13 3/8'' 21 l/s Turbo 13 mm ErgoQIC 10 Yes 8202 0850 17
MIDI Optimizer F/R EQ10-T13 1/2'' 21 l/s Turbo 13 mm ErgoQIC 10 No 8202 0850 04
MIDI Optimizer F/RD EQ10-T13 1/2'' 21 l/s Turbo 13 mm ErgoQIC 10 Yes 8202 0850 13
MIDI Optimizer F/RD EQ10-T16 1/2'' 31 l/s Turbo 16 mm ErgoQIC 10 Yes 8202 0850 12

Material removal tools 21
