Selection

guide

QIC ErgoQIC
The QIC coupling is a standard one-hand operation The ErgoQIC coupling is a ball valve coupling
coupling with high air flow performance. It is with a safety feature offering a higher
suitable for screwdrivers, assembly tools, drills flow than ordinary coupling systems. The
and grinders. The coupling is strong and durable ErgoQIC is a strong and durable full flow
and is made of hardened steel. quick coupling with no air restriction inside
the coupling. It is suitable for assembly
tools, drills and grinders. Upgrading any air
QIC S system with ErgoQIC will give the benefits of
productivity and energy efficiency. ErgoQIC is designed
The QIC S coupling is a safety coupling with a two-
step disconnection. It is suitable for applications to minimize the risk of sudden component separation and
where it is important that the potential danger of an sound bang. The safety features are according to EN 983
uncontrolled pressurized air hose is minimized. The and ISO 4414. It is made of hardened steel.
safety features are according to EN 983 and ISO The ErgoQIC disconnects in two steps; first you push in
4414. The QIC S safety coupling is easy to handle and and bend slowly – the pressurized air hose will then vent,
suitable for assembly tools and drills. The QIC safety and as a second step you can disconnect without risk of
couplings are made of hardened steel. harming the operator.

Claw MultiFlex Swivel
CLAW couplings are made from dropforged, MultiFlex Swivel is a multi-directional
hardened steel which can withstand rough connector. Once the tool is connected
treatment and ensures a long life even under difficult the hose will stay in the ideal position
conditions. The coupling head is the same for all hose however much the operator and the
sizes, which can therefore be freely combined. The tool move around. The MultiFlex bends and
recommended maximum working pressure is 10 bar. rotates 360º in all directions while the hose
stays straight.

120 Air line installation
