Accessories

MIDI MIDI
OPTIMIZER OPTIMIZER
Model MINI-K MINI-B 1/2" 3/4" MAXI-B
Mounting bracket kit a 9090 1902 00 9092 0063 01 9093 0022 01 9093 0022 01 9093 0076 15
Assembly kit a 9090 1901 90 9092 0062 71 9093 0022 02 9093 0022 02 9093 0076 31
Filter (FIL) accessories (30 μm filter element is incl with all filters)
30 μm filter element 9090 1898 00 9092 0063 31 9093 0023 04 9093 0023 04 9093 0076 61
5 μm filter element 9092 0063 61 9093 0023 05 9093 0023 05 9093 0076 71
Bowl guard 9092 0063 91
Regulator (REG) accessories b
Pressure gauge, 0-10 bar, Ø 40 mm 9090 1907 00 9090 1907 00
Pressure gauge, 0-10 bar, Ø 50 mm 9090 1172 00 9090 2052 00 9090 2052 00
Pressure gauge, 0-10 bar, Metal housing 9090 2052 01 9090 2052 01
Pressure gauge, 0-16 bar, Ø 49 mm 9090 0239 00 9090 0239 00 9090 0239 00
Pressure gauge, 0-16 bar, Ø 50 mm 9090 1657 00
Panel mounting pressure gauge, 0-10 bar, Ø 50 mm 9090 1173 00 9090 1173 00 9090 1173 00
Panel mounting pressure gauge, 0-16 bar, Ø 63 mm 9093 0076 43
Key lock for regulator -LP 9092 0074 11 9092 0074 11 9092 0074 11 9092 0074 11
Lubricator (DIM) accessories
Air distribution block kit 9090 1900 90 9092 0064 51 9093 0022 03 9093 0022 04 9093 0076 41
Bowl guard 9092 0063 91
Glass sight dome 9090 1121 00
Oil reduction plate 9093 0022 06 9093 0022 06
a Are included in combination units (FD, FTD, F/RD and FRD). Mounting bracket kits and assembly kits have to be ordered separately for separate units.
b Pressure gauge 0-10 bar is included in the combination units (F/RD and FRD). Pressure gauge has to be ordered separately for separate units.

Optimizer - Air Tool Oil
• Temperature range • Pour point
Atlas Copco Optimizer air tool oil is a white, oil based lubricant for pneumatic -25ºC to +70ºC -48ºC
tools. It has excellent antiwear properties and contains additives preventing oxi- • Density at 15ºC • Flash point COC
dation and foaming. Optimizer air tool oil provides a better working environment, 869 kg/m 3 >170ºC
compared to conventional mist lubrication oils and is recommended when • Viscosity at 40ºC
stringent demands are placed on the working environment. Safety data sheets 22 mm /s
2
(MSDS/SDS) available online.

Model Ordering No.
Optimizer 0.5 liter 9090 0000 02
Optimizer 1 liter 9090 0000 04
Optimizer 4 liter 9090 0000 06

FRL-stand

Model Ordering No.
FRL-Stand - suits all models 9090 2101 00
FRL-Stand kit c 9090 3030 02

c For impact wrenches and pulse tools up to 1/2" BSP air inlet and 32 l/s air flow requirements.
Includes: Metal stand, large metal gauge up to 10 bar, ErgoQIC 10 coupling, 0.5 liter of optimizer oil, Turbo 13 hose with length 5 meters.
The FRL-stand has BSP connection.

FRL-Stand - suits all models FRL-stand kit Optimizer - Air Tool Oil

Air line installation 115
