Single-point lubricator, DOS
Connection
thread Working Temperature
BSP Air flow l/s pressure bar range C
o
a
Model in min max min max min max Ordering No.
DOS 15B-C b 1/2 2.3 45 3.2 10 –30 o +60 o 8202 4201 73
DOS 15B-CR c 1/2 2.3 45 3.2 10 –30 o +60 o 8202 4202 72
DOS 20B-C b 3/4 2.3 53 3.2 10 –30 o +60 o 8202 4201 81
DOS 20B-CR c 3/4 2.3 53 3.2 10 –30 o +60 o 8202 4202 80
At 6 bar and DP = 0.2 bar.
a
b With counter and 7.5 m oil-filled nylon tubing.
c With 0.3 l oil container counter and 7.5 m oil-filled nylon tubing.
Accessories

FOR SINGLE POINT LUBRICATOR DOSOL

Designation Ordering No. 1
Nylon tubing 3.2 mm outside diameter
7.5 m, oil-filled 9090 1418 00
7.5 m, without oil 9090 1419 00
100 m, with oil 9090 1420 00
Barbed nipple for joining of 3.2 mm tubes 9090 1423 00
Check valve for outer end of 11 2 3 4 13 6
5
12
nylon tubing, dia ext. 3.2 mm 9090 2050 00
7
15
3 3
5
2 3 4 3 13
10
14
11
12
NOTE: When the counter TEN is used in MPL 12
installations an intermediate, black plastic
part is used (supplied with all TEN counters)
FOR MULTI POINT LUBRICATOR DOSOL between BASE and TEN.
Multiple-point lubricator, BASE, JECT 01

Designation BSP in Ordering No. Ref No. in figure Designation Ordering No.
BASE baseplate Plate 8202 4205 04 1 Oil container
Oil port 1/4 0.3 l for direct mounting 9090 1415 00
Air port 1/4 0.95 l for wall mounting (1/4" BSP female) 9090 1416 00
Clamp 1.9 l for wall mounting (1/4" BSP female) 9090 1417 00
Oil port 1/4 2 Check valve
o
Air port 1/4 1/8" BSPT 90 elbow male x 1/8" BSP female 9090 1427 00
JECT 01 oil pump Oil delivery port 1/8 8202 4203 10 1/8" BSPT, straight male x 1/8" BSP female 9090 1426 00
3 Male adapter 1/8" BSPT, straight for
tube outer diameter 3.2 mm 9090 1425 00
TEN-counter 4 Capillary tubing
When lubricating equipment with very low air consumption or 7.5 m, outer dia. 3.2 mm prefilled with oil 9090 1418 00
very short time in operation it may be difficult to set a sufficiently 7.5 m, outer dia. 3.2 mm without oil 9090 1419 00
small dose of oil. In such cases a counter is connected under- 100 m, outer dia. 3.2 mm with oil 9090 1420 00
neath the base plate BASE. The oil pumps will then be actuated 5 JECT 01 kit a 8202 4203 10
only on each, every fifth or every tenth air pulse. The air signal is 6 Side-ported air block kit 9090 1424 00
connected to the clamp underneath the counter. 7 Fiber packing for 1/8" BSP 0657 5742 00
Ordering No. 8202 4206 03 10 Counter TEN kit 8202 4206 03
11 Fiber packing for 1/4" BSP 0657 5764 00
Side-ported air block kit 12 Male adapter 1/4" BSP, straight for 9090 0715 00
If all pumps are not to be actuated simultaneously, a signal block tube outer diameter 8 mm
is installed between the oil pumps in the stack. The pumps below 13 BASE kit 8202 4205 04
the signal block will then be actuated via the base plate BASE and 14 Nylon tube, outer diameter 8 mm 9030 0060 00
those above it from a separate signal via the signal block. (sold by the meter)
15 Barbed nipple for joining of nylon tubes
Ordering No. 8202 4206 03 outer diameter 3.2 mm 9090 1423 00
16 Nylon tube outer diameter 5 mm 9030 0059 00
(sold by the meter)
a With high temperature Viton seals 8202 4203 15.
Air line installation 117
