PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

Ex E-Flare Ex-Portable Beacon
The HZ 610 series portable LED beacon has been designed for use in Zone 2, Potentially Explosive
Atmospheres. The beacon is ideally suited for marking /warning of temporary hazards in an explosion
proof environment. It is of robust construction and can be set for either a Flashing or Static (steady
On) light mode by twisting the lens to the left or to the right. The beacon comes with a wide range of
accessories making the product extremely versatile in a wide range of applications. The beacon requires
two ‘D’ cell Alkaline batteries for operation (not supplied) which give over 40 hours life. product extremely
versatile in a wide range of applications. The beacon requires two ‘D’ cell Alkaline batteries for operation
(not supplied) which give over 40 hours life.
Specification Features
Ex Classification Zone 2 Ex II 3G EX 11C T4 Gc • Activates flashing mode by turning the
Nominal Voltage Powered from 2 x 1,5v D cell lens links.
batteries (not included) • Activates steady mode by turning the lens
Flash Frequecy 160 FPM on-off-on.
Operation time 40 hours of peak brightness • LED long life
operation on 1 set of batteries • 360° visibility Lens colours:
Housing Material High Impact UV Stable ABS Body • Low battery indicator
Lens Material High Impact UV Stable • Shock resistant
• 40 hours life on 1 set of batteries
Polycarbonate Lens Housing colour:
Operating temp -20 to +50°C • Ultra quick installation
• Versatile accessory options
• Zone 2 Ex II 3G EX 11C T4 Gc.
IP
2,75kg 66/67 LED Portable
