SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

BExBG21 Ex-Xenon Beacon 21Joule
The BExBG21 21 Joule beacons are ideal for general signalling duties whilst their robust construction
makes installation in the harshest of environments possible. The BExBG21 has three distinct user
selectable flash patterns and for units with DC operating voltages a second stage flash pattern can
be selected remotely. Additional features include a stainless steel guard and stainless steel mounting
bracket as standard.
Specification Features
Energy 21 Joules (21Ws) • Automatic synchronisation on multi-beacon
Supply Voltage 24Vdc, 48Vdc, 115Vac, 230Vac system.
Flash rate 1Hz (60 fpm) • Beacons can be set to ‘flip-flop’ alternating
Peak/effective Candela 110,780 cd / 485 cd mode with other units on multi-beacon systems.
Housing alternatives Ex d • Xenon tubes mechanically secured against
Cable entries Dual M20 ISO (one stopping shock & vibration
• Glass lens & Stainless Steel guard
plug included)
Terminals 0.5 to 4.0mm² cables • Very large termination area.
• Ratchet adjustable stainless steel ‘U’ bracket.
Measurements Ø153*246MM • IN & OUT terminals (Ex de version only). Lens colours:
Line monitoring Min. 500 Ohm 2w,or 3k3 Ohm
0.5w res. or diode with Exd Approvals:
enclosure (dc) • ATEX certificate: KEMA 0ATEX2006, Housing colours:
EN 60079-0 : 2006, EN 60079-1 : 2007, Other colours available
EN 61241-0 : 2006, EN 61241-1 : 2004 on request.
IP • IECEx certificate: IECEx KEM 10.0002,
IEC 60079-0 : 2004 (Ed4), IEC 60079-1 : 2007 (Ed6),
IEC 61241-0 : 2004 (Ed1), IEC 61241-1 : 2004 (Ed1)
2,75kg 66/67 Xenon
• Inmetro certificate: 10-IEx-0010.
BExBGL1 Ex-Multi-Function LED Beacon
With an array of 32 high output L.E.D.s the BExBGL1 unit is a multi-functional beacon suitable for all
signalling applications. The robust construction makes installation in the harshest of environments
possible. Additional features include UV stable prismatic lens, stainless steel guard and mounting bracket
as standard. Multi-function: The BExBGL1 features a total of 9 modes of operation: 4 rotating effect
modes, 4 flashing modes and a steady mode for use in indicator / status applications. Based on the mode
selected the user can also select two alternative L.E.D. modes remotely.
Specification Features
Supply Voltage 10-50Vdc, 115Vac, 230Vac • Glass dome with optically enhanced prismatic
Flash rate 9 Modes PC lens
Effective Candela 11 cd • Stainless Steel guard
Housing Alternatives Ex d • Very large termination area.
Cable entries Dual M20 ISO (one stopping • Ratchet adjustable stainless steel ‘U’ bracket.
plug included) Approvals:
Terminals 0.5 to 4.0mm² cables • ATEX certificate: KEMA 00ATEX2006,
Measurements Ø153*246MM EN 60079-0 : 2006, EN 60079-1 : 2007, Lens colours:
Line monitoring Min. 500 Ohm 2w,or 3k3 EN 61241-0 : 2006, EN 61241-1 : 2004
Ohm 0.5w res. or diode • IECEx certificate: IECEx KEM 10.0002,
with Exd enclosure (dc) IEC 60079-0 : 2004 (Ed4), IEC 60079-1 : 2007 (Ed6), Housing colours:
IEC 61241-0 : 2004 (Ed1), IEC 61241-1 : 2004 (Ed1) Other colours available
• GOST-R certificate: POCC GB.JB05.B02205 on request.
IP • Safety-integrity suitability: SIL1
• Inmetro certificate: 10-IEx-0010
2,75kg 66/67 LED

E2xB05 Zone2 Ex-Xenon Beacon 5Joule
The hazardous area E2xB05 Xenon strobe beacon is ULcertified for Zone 2 applications and also UL
approved for Class I Div 2 applications. The E2xB05 is a 5 Joule Xenon strobe beacon with a 1Hz (60 fpm)
flash rate. The E2x range features enclosures manufactured from lightweight, high performance PPS
which, with its corrosion proof properties, is suitable for the harshest of environments.
Specification Features
Energy 5 Joules (5Ws) • Very large termination area.
Supply Voltage 12Vdc, 24Vdc, 48Vdc, • Ratchet adjustable stainless steel ‘U’ bracket.
115Vac, 230Vac • Stainless Steel dome guard as standard
Flash rate 1Hz (60 fpm) • Xenon tube mechanically secured against
Peak/effective Candela 31,950 cd / 101 cd vibration/shock.
Housing Alternatives EEx nA • User replaceable Xenon tube assembly.
Cable entries Dual M20 ISO (one stopping Approvals:
plug included) • UL File ref: E245313 Lens colours:
01 - ATEX VISUAL Currently not available with ATEX approval Housing colours:
Terminals
0.5 to 4.0mm² cables
Ø153*246MM
Measurements

IP

Xenon
66/67
1,48kg
