PRODUCT PRODUCT AVAILABLE SIGNALLING
INFORMATION IMAGE COLOURS SIGNALLING

E2xB10 Zone2 Ex-Xenon Beacon 10Joule
The hazardous area E2xB10 Xenon strobe beacon is UL certified for Zone 2 applications and also UL
approved for Class I Div 2 applications. The E2xB10 is a 10 Joule Xenon strobe beacon with a 1Hz (60 fpm)
flash rate. The E2x range features enclosures manufactured from lightweight, high performance PPS
which, with its corrosion proof properties, is suitable for the harshest of environments.
Specification Features
Energy 10 Joules (5Ws) • Very large termination area.
Supply Voltage 12Vdc, 24Vdc, 48Vdc, • Ratchet adjustable stainless steel ‘U’ bracket.
115Vac, 230Vac • Stainless Steel dome guard as standard
Flash rate 1Hz (60 fpm) • Xenon tube mechanically secured against
Peak/effective Candela 57,270 cd / 255 cd vibration/shock.
Housing alternatives EEx nA • User replaceable Xenon tube assembly.
Cable entries Dual M20 ISO (one stop- Approvals:
ping plug included) • UL File ref: E245313
Terminals 0.5 to 4.0mm² cables
Measurements Ø153*246MM Lens colours:
Currently not available with ATEX approval
Housing colours:
IP

1,48kg 66/67 Xenon

BExCBG05-05 Ex- Dual Xenon Beacon
The flameproof BExCBG05-05 dual xenon beacons are suitable for Zone 1, 2, 21 & 22 applications.
The BExCBG05-05D dual 5 Joule beacons are ideal for general signalling duties whilst their robust
construction makes installation in the harshest of environments possible.
Specification Features
Energy 5 Joules (5Ws) x2 • Automatic synchronisation on multi-beacon
Supply Voltage 12Vdc, 24Vdc, 48Vdc, system.
115Vac, 230Vac • Beacons can be set to ‘flip-flop’ alternating mode
Flash rate 1Hz (60 fpm) with other units on multi-beacon systems.
Peak/effective Candela 34,812 cd / 105 cd x2 • Xenon tubes mechanically secured against shock
Housing alternatives Ex d / Ex de & vibration
Cable entries Dual M20 ISO (one stopping • Glass lens & Stainless Steel guard
plug included) • Very large termination area.
Terminals 0.5 to 4.0mm² cables • Ratchet adjustable stainless steel ‘U’ bracket.
Measurements Ø153*246MM Approvals:
Line monitoring Min. 500 Ohm 2w,or 3k3 • ATEX certificate: KEMA 01ATEX2222X, Lens colours:
Ohm 0.5w res. or diode EN 60079-0 : 2006, EN 60079-1 : 2007,
with Exd enclosure (dc) EN 61241-0 : 2006, EN 61241-1 : 2004
• IECEx certificate: IECEx KEM 10.0024, Housing colours:
IEC 60079-0 : 2004 (Ed4), IEC 60079-1 : 2007 (Ed6), Other colours available
IEC 61241-0 : 2004 (Ed1), IEC 61241-1 : 2004 (Ed1) on request.
IP • GOST-R certificate: POCC GB.JB05.B02205
• Inmetro certificate: 10-IEx-0010
4,3kg 66/67 Xenon

BExMP Ex-Plated Assemblies
The BEx range is manufactured from marine grade LM6 Aluminium Alloy which has been chromated and
powder coated offering superb resistant to corrosion even under the mostsevere operating conditions.
Standard sets are certified ATEX EX II 2G Exd IIB T4 but other options are available for higher gas groups,
temperature ratings and approvals.
The BEx range is manufactured from marine grade Specification Approval
LM6 Aluminium Alloy which has been chromated and BExBG05D ATEX/IECEx
powder coated offering superb resistant to corrosion 5 Joule GOST-R
even under the mostsevere operating conditions. Xenon Beacon
Standard sets are certified ATEX EX II 2G Exd IIB T4 BExBG10D/15D ATEX/IECEx
but other options are available for higher gas groups, 10/15 Joule GOST-R
temperature ratings and approvals. Xenon Beacon
• Multi Function LED BExBG21D ATEX/IECEx
- Status Light mode 21 Joule GOST-R
- Flashing modes Xenon Beacon
- Rotating modes BExBGL1D ATEX/IECEx Lens colours:
• Xenon Strobe 5, 10, 15 and 21J versions L.E.D Array GOST-R
• Alarm Sounders 110dB(A) and 117dB(A) Beacon Colours available on request.
versions BExS110D ATEX/IECEx
• Junction Box 110dB(A) GOST-R Housing colours: 01 - ATEX VISUAL
Alarm Sounder Colours available on request.
IP BExS120D ATEX/IECEx
GOST-R
117dB(A)
Alarm Sounder
2,75 - 10kg 66/67 Junction Box
