SIGNALLING

SIGNALLING Accessories

Visibility Sensor and assembly kits

PRODUCT PRODUCT AVAILABLE
INFORMATION IMAGE COLOURS

Technical Data Visibility Sensor Visibility Sensor
Rated Voltage Electronics 12 / 50 Vdc
Hood Heating 24 Vac/dc
Power Concumption Incl. Window Heater 3 W @ 12 Vdc
Incl. Hood Heater 65 W
Functional principle Optical forward scattering
Relay contacts 3 pieces, programmable visibility alarm thresholds
and delays can be configured, error message
Features
Serial ports RS-232, RS 485
The visibility sensor identifies different
Analog exit 0 -1 mA, 4 - 20 mA precipitation types, such as rain, drizzle, leet,
Operating temperature - 40 °C / + 60 °C snow and other weather-related constraint
Relative humidity 0 - 100% factors such as fog, mist or haze caused
by smoke and sand. It allows a reliable
Dimensions (HxWxD) 199 x 695 x 404 mm determination of visibility over a range from 10 to
20,000 meters and is designed for both onshore
and offshore use.
IP

3kg 66

Ordering details Assembly Kits
Accessories Article numbers
Circular mounting base, aluminium (seawater-resistant)
Waisted mounting base, aluminium (seawater-resistant)
Square mounting base, aluminium (seawater-resistant)
Mounting pillar, aluminium (seawater-resistant)
Outrigger, aluminium, as support for lightning arrester
Fixing screw set stainless steel (A4) natural
Stainless steel cable ties, natural, for outdoor use, minimum On request Features
retention force 670 N
01 - WIDE AREA AVIATION nished on the lamp side with a Hummel M23 stainless steel 280 13 00 0 001 kits, where the extent and compilation of
Cable ties, plastic for indoor installation
The range of accessories for Pfannenberg
Sturdy UV and weather-resistant cable, of various lengths, fi
obstruction lights includes several assembly
connector. The side opposite the cable can be customized
components vary depending on the respective
freely
installation tasks. In general, the Pfannenberg
Cable glands, fi ller plugs and sealing plugs
package for the provision of obstructions
lights and their installation also includes the
Cable lugs / cable end ferrules for replacement sets
corresponding sets.
Fuses for replacement sets
Service terminals
Lighting arrester for installation at the outrigger
Visibility Sensor PWD 20W
280 13 00 0 004
Thermo-Reflector
