RTP

pneumatic nutrunners

The light weight of the RTP NUTRUNNER will
surprise you, yet its high speed motor has the power
you need to tighten big bolts. A robust, lightweight
reaction bar absorbs the torque. Noise and vibration
levels are lower than in traditional impact wrenches.

Among the smallest on the market, the RTP’s slim
gearpack gives you effortless access to bolts in
cramped spaces. Tightening accuracy and repeat-
ability are high.

Plug & play! Simply connect the RTP to your air line
and start working with it. The torque output of the
RTP is adjusted with an Atlas Copco FRL air pres-
sure unit, helping to prolong the lifetime and torque
accuracy of the tool. The tool’s exchangeable drive
simplifies maintenance and cuts repair costs.

RTP nutrunner Kit

Air con- Rec. Air
Bolt Square Min torque Max torque Free a CS sumption at hose inlet
size drive at 1,5 bar at 6.3 bar speed Weight Length distance free speed size thread
Model mm in Nm Nm r/min kg mm mm l/s mm in Ordering No.
RTP1300-HR20 20-27 3/4 320 1300 20 3.7 248 32 23 13 3/8 8431 1013 10
RTP2600-HR25 20-36 1 700 2600 10 5 300 34 23 13 3/8 8431 1026 10
RTP4100-HR25 30-45 1 1000 4100 10 8.7 335 41 31 13 3/8 8431 1040 10
RTP8100-GIR38 33-52 1 1/2 2200 8100 10 13.5 444 51 50 13 1/2 8431 1081 10
a Weight excluding reaction bar.
NOTE: For all models in the table declared noise and vibration emissions according to ISO 28927-2 and ISO 15744. Sound pressure level for RTP1300 HR20 is
90 dB(A), RTP2600-HR25 90 dB(A), RTP4100-HR25 90 dB(A), RTP8100-GIR38 99 dB(A) and vibration value for all models are <2.5 m/s . 2

86 Fastening tools
