Productivity Kits

Model Economical flow Max air flow Hose, 5 m Coupling Lubrication Ordering No.
For small nutrunners with 3/8" BSP air inlet
MIDI Optimizer F/RD EQ08-C10 13 l/s 16 l/s Cablair 10 mm ErgoQIC 08 Yes 8202 0850 07
For small nutrunners with 1/4" BSP air inlet
MIDI Optimizer F/RD EQ08-C10 13 l/s 16 l/s Cablair 10 mm ErgoQIC 08 Yes 8202 0850 03
MIDI Optimizer F/RD EQ10-R10 13 l/s 16 l/s Rubair 10 mm ErgoQIC 10 Yes 8202 0850 16
For nutrunners with 3/8" BSP air inlet
MIDI Optimizer F/RD EQ10-C13 21 l/s 23 l/s Cablair 13 mm ErgoQIC 10 Yes 8202 0850 02
For nutrunners with 1/4" BSP air inlet
MIDI Optimizer F/RD EQ10-C13-1/4 27 l/s 23 l/s Cablair 13 mm ErgoQIC 10 Yes 8202 0850 11
For nutrunners with 3/8" BSP air inlet
MIDI Optimizer F/RD EQ10-T13 21 l/s 35 l/s Turbo 13 mm ErgoQIC 10 Yes 8202 0850 17
For nutrunners with 1/2" BSP air inlet
MIDI Optimizer F/R EQ10-T13 21 l/s 35 l/s Turbo 13 mm ErgoQIC 10 No 8202 0850 04
MIDI Optimizer F/RD EQ10-T13 21 l/s 35 l/s Turbo 13 mm ErgoQIC 10 Yes 8202 0850 13

Accessories

For LMP24 Swivelling suspension yoke LMP/LTP61

Model Ordering No. Model Ordering No.
Hose nipple 9000 0247 00 Mounting dia Ø 54 mm
Swivel attachment 4210 2249 80 PH/H 100-13 4210 3088 80
Exhaust hose 4210 2053 00 PH/H 170-13
Support handle 4110 1355 82 PH/H 230-19
(for H/HR002 only) PH/H 350-20
Spindle extension PH/H 500-20
115 mm x 1/2" 4210 2154 80 PH/H 700-25
(for H/HR002 only) PH/H 900-25
50 mm x 3/8" 4210 2158 80 Mounting dia Ø 60 mm
(for H/HR011/005 only) HR 100-13 4210 3088 84
1/4" hex bit holder 4021 0443 00 HR 170-13
(for H/HR011/005 only) HR 230-19
1/2" square adapter 4210 2157 80 Mounting dia Ø 63.5 mm
(for H/HR011/005 only) H 1900-38 4210 3088 83
H 2800-38
H 3800-38
Mounting dia Ø 67 mm
HR 350-20 4210 3088 82
For LMP/LTP61 HR 500-20
PHR/HR 700-25
PHR/HR 900-25
HR 1900-38 4210 3088 85
Model Ordering No. HR 2800-38
Hose nipple 9000 0242 00 HR 3800-38
Exhaust hose 4210 2201 00 Mounting dia Ø 83.5
Protective cover PH/H 1500-25 4210 3088 81
Standard LTP61 4210 4672 00 PHR/HR 1500-25
LTP 61 with MT unit 4210 4672 01
Multi torque selector LTP61 4210 4636 95
Quick change retainer
– 1/2" square models 4250 1190 00
– 3/4" square models 4210 3476 80
– 1" square models 4210 3524 80
Shut-off override for LTP61 4210 3545 80
Swivelling type MultiFlex 8202 1350 22
connector 3/8" (BSP)
Swivelling type MultiFlex 8202 1350 28
connector 3/8" (NPT)

84 Fastening tools
