Blow guns

and test equipment

Blow Gun BG-series
Blow guns in the BG Series are a robust, user friendly
solution for all cleaning applications. The plastic body
offers flexibility in handling for both left and right
handed users. It insulates against cold and reduces
the risk of scratches to worksurfaces. The blow gun
has excellent throttling properties allowing easy regu-
lation of the air flow.

• High flow capacity
• Suspension
• Plastic body to avoid scratches
• Air inlet thread in brass
• Star tip availability for
improved safety
• Applicable standards: OSHA STD1-13.1, OSHA
1910.95 (b).

Working Air inlet
pressure Air flow Weight thread
Model Version bar l/s kg lb BSP Ordering No.
BG 2603-HF Long tube, high flow 6.3 7.5 0.13 0.29 1/4 8202 1006 04
BG 2604-SHF Short tube 6.3 4.3 0.12 0.26 1/4 8202 1006 05
BG 2605-STSS Short tube, star tip 6.3 6.6 0.12 0.26 1/4 8202 1006 06
BG 2606-STS Long tube, star tip, silencer 6.3 6.3 0.14 0.31 1/4 8202 1006 07

Test Equipment

Air tool simulator
In order to check whether the pressure or the flow is sufficient
the air tool simulator can be connected instead of the tool. The
simulator is delivered with different connections.
Ordering No. 4145 0698 81.

Pressure control unit
The unit consists of a high quality pressure gauge and the nec-
essary couplings for checking the air pressure at the air inlet of
the machine.
Ordering No. 4145 0699 81.

166 Air line installation
