PVC
Hose for heavy-duty applications
PVC hose has high resistance to abrasion, which makes
it the ideal hose for tough working environments. It is
mainly recommended for indoor use.
• Long service life.
• Pliable.
• Transparent.
• Working temperature -15ºC to +60ºC.

Hose inside Hose Max working Max rec. Weight per
dia outside dia pressure air flow 30 m coil
a
b
Model mm in mm bar l/s kg Ordering No.
PVC 03 3.2 1/8 7 20 0.7 1.4 9093 0037 21
PVC 05 5 3/16 9 10 2.1 1.9 9093 0037 51
PVC 06 6.3 1/4 11 10 4 2.5 9093 0037 81
PVC 08 8 5/16 12 10 7.5 2.9 9093 0038 11
PVC 10 10 3/8 14 14 13 3.7 9093 0038 41
PVC 13 12.5 1/2 18 13 21 5.9 9093 0038 71
PVC 16 16 5/8 22 12 43 7.2 9093 0039 01
PVC 20 19 3/4 25 10 75 8.3 9093 0039 31
PVC 25 25 1 32 10 125 12.5 9093 0039 61
a With a safety factor of 3 at 20°C (at the max temp of +60°C the working pressure should be reduced by 50%).
b The pressure drop will be 0.2 bar on a hose length of 5 m.

POLUR
High resistance polyurethane hose
Polur hose is the most environmentally friendly
solution. It has high resistance to abrasion and it is oil
resistant. Polur hose has a much longer lifetime than
PVC hoses. Polur is ideal in tough working conditions
due to its flexibility, even at minus degrees. Polur is
recommended for indoor and outdoor use.

• Oil resistant.
• Flexible.
• Long service life.
• Working temperature -30ºC to +60ºC.

Hose Hose Max working Max rec. Weight per
inside dia outside dia pressure air flow 25 m coil
b
a
Model mm in mm bar l/s kg Ordering No.
POLUR 08 8 5/16 12 20 7.5 2.2 8202 0601 08
POLUR 10 10 3/8 14 16 13 2.5 8202 0602 10
POLUR 13 13 1/2 18 13 21 4.0 8202 0603 13
a With a safety factor of 3 at 20°C (at the max temp of +60°C the working pressure should be reduced by 50%).
b The pressure drop will be 0.2 bar on a hose length of 5 m, including 2 nipples and at an inlet pressure of 7 bar.
Air line installation 151
