Pumps

air and electric

Pumps in the Rapid torc series are designed for all
hydraulic torque wrench applications. Panther pumps
are variable piston models with the smallest ratio of
weight/oil flow on the market.
The pumps are available in two versions: air driven or
electric driven, 110V or 220V. They come in three sizes:
small, medium and large.

Air driven pumps
Oil flow
Oil flow
Oil flow
Dimensions Weight Oil capacity 1,250 psi/86 3,600 psi/250 10,000 psi/700
(LxWxH) bar bar bar
Li-
Model inches mm lb kg Gal- ters cu.in/ l/min cu.in/ l/min cu.in/ l/min Ports Ordering No.
min
min
min
lons
340.3 x
Panther A110 Small frame 13.4 x 13.7 347.9 x 33 15 0.5 1.89 275 4.5 67 1.1 24 0.4 1 8434 2040 19
x 16.5 419.1
340.3 x
Panther A110 Full frame 13.4 x 13.7 347.9 x 33 15 0.5 1.89 275 4.5 67 1.1 24 0.4 1 8434 2040 17
x 16.5 419.1
15.7 x14.9 398.7x
Panther A380 x 18.1 378.4 x 48 22 1.5 5.67 701 11.5 213 3.5 79 1.3 4 8434 2056 22
459.7
18 x 10.5 457.2 x
TigAir x 18.5 266.7 x 75 34 2.5 9.5 - - - - 72 1.1 1 8434 2059 62
439.9
Electric pumps
Dimensions Intercooler Oil flow Oil flow Oil flow
(LxWxH) Weight system 1,250 psi/86 bar 3,600 psi/250 10,000
bar psi/700 bar
l/
l/
Model mm kg cu.in/ l/min cu.in/ min cu.in/ min Ports Ordering No.
min
min
min
Panther 025 with Handle 110V 320 x 210.8 x 388.6 15 no 195 3.2 l/min 54 0.9 21 0.35 1 8434 2040 31
Panther 025 with Full frame 110V 320 x 210.8 x 388.6 15 no 195 3.2 l/min 54 0.9 21 0.35 1 8434 2040 33
Panther 025 with Handle 220V 320 x 210.8 x 388.6 15 no 195 3.2 l/min 54 0.9 21 0.35 1 8434 2130 22
Panther 025 with Full frame 220V 320 x 210.8 x 388.6 15 no 195 3.2 l/min 54 0.9 21 0.35 1 8434 2059 54
Panther 055 110V 439.4 x 238.7 x 469.9 22 yes 391 6.4 l/min 110 1.8 42 0.7 4 8434 2040 35
Panther 055 220V 439.4 x 238.7 x 469.9 22 yes 391 6.4 l/min 110 1.8 42 0.7 4 8434 2040 37
Lynx 110V 541.3 x 435.3 x 460.2 34 Optional - - - - 56 0.9 1 8434 2059 61
Accessory
Optional
Lynx 220V 541.3 x 435.3 x 460.2 34 Accessory - - - - 56 0.9 1 8434 2059 59
10.5 l/
Panther 150 110V 460 x 300 x 440 33 yes 641 min 153 2.5 92 1.5 4 8434 2040 39
Panther 150 220V 460 x 300 x 440 33 yes 641 10.5 l/ 153 2.5 92 1.5 4 8434 2040 41
min
Fastening tools 101
