SIGNALLING

SIGNALLING IS-CP4A/B-BG

Break Glass Call Point

PRODUCT PRODUCT AVAILABLE
INFORMATION IMAGE COLOURS

The IS-CP4A-BG and IS-CP4B-BG break glass manual call points are approved for Zones 0, 1, 2, 21 & 22 requiring intrinsically safe equipment for the
control of fire and gas alarm systems. Available with and without monitoring resistors all versions are certified to ATEX and IECEx standards.
The IS-CP4 range features enclosures manufactured from corrosion proof, marine grade, copper free LM6 (A413) aluminium which is phosphated and
powder coated.

Specification Features
Alternative housing colours are available to meet
•
IS-CP4A-BG II 1G Ex ia IIC T6 Ga specific requirements.
II 2D Ex t IIIC T60°C Db • DIN rail mounted terminal blocks: 8 x 2.5mm²
BExCP3B-BG II 1G Ex ia IIC T4 Ga • Stainless Steel lift flap
II 2D Ex t IIIC T70°C Db • Metalised Polyester “Duty” label.
Ambient Ta = -40°C to +55°C • Series and/or End of Line resistors.)
Housing material Marine grade copper free LM6 Aluminium
Housing finish Phosphated & powder coated finish: anti-corrosion
Cable entries 2 x M20 clearance top and 1 x M20 clearance side.
Back box can be rotated to give 2 x bottom and 1 x side entries
Stopping plugs 2 x nylon plugs as standard Brass and stainless steel plugs
optional
Terminals 6 x 4.0mm² cables

Approvals
ATEX certificate SIRA 09ATEX2287X,
IEC 60079-0:2007 Ed 5, EN 60079-11:2007,
EN 60079-26:2007,
EN 61241-1:2004
IECEx certificate IECEx SIR 09.0122X,
IEC 60079-0:2007-10 Edition: 5,
IEC 60079-11:2006 Edition: 5,
IEC 60079-26:2006 Edition: 2,
IEC 61241-1:2004 Edition: 1

01 - ATEX CALLPOINTS 0,5kg IP Other colours available Colours:

on request.

66
