GNExCP6A-BG SIGNALLING
Break Glass Call Point SIGNALLING

PRODUCT PRODUCT AVAILABLE
INFORMATION IMAGE COLOURS

The GNExCP6A manual call points are available as break glass, push button or tool reset versions. They are approved for Zone 1, 2, 21 and 22 hazardous
areas for the control of fire and gas alarm systems. Available with either single or double pole change over switches. All versions are certified to ATEX and
IECEx standards.

Specification Features
• Alternative housing colours are available to meet
GNExCP6A II 2G Ex e d IIC T6 Gb specific requirements.
II 2D Ex t IIIC T60°C Db • Single or double pole c/o switch.
Ambient Ta = -40°C to +55°C • Metalised polyester or stainless steel “Duty” label.
Housing material GRP - glass reinforced polyester (UV stable)
Cable entries 2 x M20 clearance top and 1 x M20 clearance side.
Back box can be rotated to give 2 x bottom and 1 x side entries
Stopping plugs 2 x nylon plugs as standard Brass and stainless steel plugs
optional
Terminals 6 x 4.0mm² cables

Approvals
ATEX certificate Sira 09ATEX3286X,
IEC 60079-0:2007 Ed 5, EN 60079-1:2004,
EN 60079-7:2007, IEC 60079-18:2009 Ed 3,
EN 61241-1:2004
IECEx certificate IECEx SIR 09.0121X,
IEC 60079-0:2007-10 Edition: 5,
IEC 60079-1:2003 Edition: 5,
IEC 60079-18:2009 Edition: 3,
IEC 60079-7:2006-07 Edition: 4,
IEC 61241-1:2004 Edition: 11

Colours: 01 - ATEX CALLPOINTS
Other colours available
on request.
IP
0,5kg 66
