SIGNALLING

SIGNALLING INFORMATION PRODUCT AVAILABLE

PRODUCT
COLOURS

BExSB1
The BExSB1 ideally suits applications requiring a traditinal bell sound designed to warn, call and signal
in areas with explosive atmospheres. The protection type II 2G EEx de IIC T6 allows the signalling bell to
be used without restriction in all Ex areas classified Zone 1 or 2. The signalling bell produces a sound
volume of approx. 105dB(A) at 1 metre. The emphasis of the ring is at approx. 1000Hz, as a result of which
the signal stands out clearly against lower frequency ambient noises. We offer the’Hootronic’ range which
offers the same sound from an all-electronic solution.
Ex Alarm Bell Features
Maximum output 100dB(A) @ 1metre • Explosion protection is ensured by the
No. of tones 1 flameproof enclosure of the driver system and
No. of stages 1 increased safety terminal box. The enclosure is
Supply Voltage 24Vdc, 115Vac, 230Vac made completely of GRP (glass-fibre reinforced
Effective range 100m @ 1KHz polyester) thus guaranteeing protection against
Housing material Glass-fibre reinforced corrosion. All D.C. versions are equipped with an
polyester (GRP) electronic contact breaker which considerably
Cable entries 2 x M20 ISO cable gland increases service life compared with other Colours:
entries available devices.
Measurements Ø200*270MM

IP

3,5kg 66 Bell

761
The Ex signal horn 761 can be used for a range of applications in gas and dust explosion endangered
areas, e.g. in joinery and wood processing plants. Zone 1 and 2, Zone 21 and 22 suitable for use in areas
liable to explosion caused by both gas or dust without the need for additional accessories.
Ex Signal horn Fixing
Maximum output 105dB(A) @ 1 metre Wall mounting, base mounting
No. of tones 1
No. of stages 1 Explosion protection
Supply Voltage 24Vdc/ac, 48Vdc, 115Vac, II 2G Ex emb II T5
230Vac II 2D Ex td A21 IP65 T70°C
Effective range 60m @ 1KHz
Housing material PC Approval
Cable entries 1 xM16*1,5 entries BVS 03 ATEX E 118X
Measurements 232*178*108MM
Colours:

IP

1,6kg 66 EL Sounder

718
Intrinsically safe Ex installation buzzer for Zone 1 and 2 (EEx ib - not for zone 0) For use with a Zener
Barrier If added the optinal Dust cap this buzzer can be used in more demanding areas. Low current
consumption and Continuous tone makes this unit an exelent alternativ for cabinets etc in Ex areas.
Ex Electronic Installation Buzzer Fixing
Maximum output 90dB(A) @ 1 metre Panel mount
No. of tones 1
No. of stages 1 Explosion protection
Supply Voltage 24V Zener barrier II 2G Ex ib IIC T4 / T5 / T6
Effective range 10m @ 1KHz
Housing material PC Approval
Measurements 43*13MM DMT 98 ATEX E 005 X
01 - ATEX AUDIBLE 0,1kg IP Buzzer Colours:

30/43
