SIGNALLING

SIGNALLING E2xS112

Alarm Sounder

The hazardous area E2xS112 alarm sounder
is certified for Zone 2 applications and also UL
approved for Class I Div 2 applications.

Currently not available with ATEX approval

PRODUCT PRODUCT AVAILABLE
INFORMATION IMAGE COLOURS

With a nominal sound level output of 116dB(A) at 1 metre and a choice of 45 alarm tones and 3 remotely selectable stages the E2xS112 alarm sounder
horn is suitable for all general signalling duties. The E2x range features enclosures manufactured from lightweight, corrosion proof PPS and high impact,
fire retardant ABS re-entrant flare horns; both of which are suitable for the harshest of environments.

Ex Alarm Sounder Features
• Automatic synchronisation on multi-sounder
Maximum output 116dB(A) @ 1 metre system.
No. of tones 45 (UKOOA / PFEER compliant) • Very large termination area.
No. of stages 3 • Ratchet adjustable stainless steel ‘U’ bracket.
Supply Voltage 24Vdc, 48Vdc, 115Vac, 230Vac
Effective Range 100m @ 1KHz
Ingress protection IP66/67
Cable entries 2 x M20 ISO cable gland entries
Measurements Ø181*270MM
Approvals
UL File ref E230764
UL Version:
E2xS112UL**
Class I, Div 2, Grps A,B,C,D T3C (160°C) at +55°C
Class I, Div 2, Grps A,B,C,D T4 (135°C) at +40°C
Class II, Div 2, Grps F & G T6 (85°C) at +40°C
Class II, Div 2, Grps F & G T5 (100°C) at +55°C
Class III, Div 1, T6 (85°C) at +40°C
Class III, Div 1, T5 (100°C) at +55°C
** = Voltage reference

01 - ATEX AUDIBLE 3,0kg IP EL Sounder Bell Colours:

66/67
