PRODUCT PRODUCT ACCESSORIES Ex CABLEGLANDS & Ex-CABLEGLANDS & ACCESSORIES
INFORMATION IMAGE

ISO Pipe Parallel ISO 228 BS2779 (BSPP, C, G, R, PF & Tpy 6) PG DIN 40430
ISO Pipe Taper ISO 7-1 BS21 (BSPT, Gc, Gk, Rk, PT & Kmpy 6) Thread Peppers Pitch TPI Major Dia Thread Bore Max
Thread Peppers Pitch TPI Major Dia Thread Bore Max Reference Length Clearence
Reference Length Clearence Hole Dia
Hole Dia PG7 PG7 1.27 20.0 12.50 16.0 8.0 13.20
1/2” 050BSP/BST 1.81 14.0 20.96 19.9 14.1 21.66 PG9 PG9 1.41 18.0 15.20 16.0 10.0 15.90
3/4” 075BSP/BST 1.81 14.0 26.44 20.1 19.0 27.14 PG11 PG11 1.41 18.0 18.60 16.0 13.5 19.30
1” 100BSP/BST 2.31 11.0 33.25 25.0 25.0 33.95 PG13.5 PG13.5 1.41 18.0 20.40 16.0 14.0 21.10
1-1/4” 125BSP/BST 2.31 11.0 41.91 25.6 32.0 42.61 PG16 PG16 1.41 18.0 22.50 16.0 16.0 23.20
1-1/2” 150BSP/BST 2.31 11.0 47.80 26.0 38.0 48.50 PG21 PG21 1.59 16.0 28.30 16.0 21.0 29.00
2” 200BSP/BST 2.31 11.0 59.61 26.9 49.0 60.31 PG29 PG29 1.59 16.0 37.00 16.0 29.0 37.70
2-1/2” 250BSP/BST 2.31 11.0 75.18 39.9 60.0 75.78 PG36 PG36 1.59 16.0 47.00 16.0 38.0 47.70
3” 300BSP/BST 2.31 11.0 87.88 41.5 75.0 88.58 PG42 PG42 1.59 16.0 54.00 16.0 45.0 54.70
PG48 PG48 1.59 16.0 59.30 16.0 50.0 60.00
NPT ANSI B1.20.1
Thread Peppers Pitch TPI Major Dia Thread Bore Max ET Imperial Conduit BS31
Reference Length Clearence
Hole Dia Thread Peppers Pitch TPI Major Dia Thread Bore Max
3/8” 038NPT 1.41 18.0 17.15 15.3 10.0 17.85 Reference Length Clearence
Hole Dia
1/2” 050NPT 1.81 14.0 21.34 19.9 14.1 22.04 5/8” 058ET 1.41 18 15.88 16 10 16.58
3/4” 075NPT 1.81 11.5 26.67 20.1 19.0 27.37 3/4” 075ET 1.59 16 19.05 16 14 19.75
1” 100NPT 2.20 11.5 33.40 25.0 25.0 34.10 1” 100ET 1.59 16 25.40 16 18 26.10
1-1/4” 125NPT 2.20 11.5 42.16 25.6 32.0 42.86 1-1/4” 125ET 1.59 16 31.75 16 24 32.45
1-1/2” 150NPT 2.20 11.5 48.26 26.0 38.0 48.96 1-1/2” 150ET 1.81 14 38.10 16 32 38.80
2” 200NPT 2.20 11.5 60.33 26.9 49.0 61.03 2” 200ET 1.81 14 50.80 16 41 51.50
2-1/2” 250NPT 3.18 8.0 73.03 39.9 60.0 73.73 2-1/2” 250ET 1.81 14 63.50 16 53 64.20
3” 300NPT 3.18 8.0 88.90 41.5 75.0 89.60 3” 300ET 1.81 14 76.20 16 64 76.90
3-1/2” 350NPT 3.18 8.0 101.60 42.8 88.0 102.30
4” 400NPT 3.18 8.0 114.30 44.0 100.0 115.00
5” 500NPT 3.18 8.0 141.30 46.7 120.0 142.00 03
