STRAPPING & BUNDLING

STRAPPING & BUNDLING
Polyamide Cable Ties

Our Cable ties are made exclusively of polyamide
6.6 so that they do not cause issues of material
separation during recycling or interferences in
electronic equipment.

PRODUCT PRODUCT
INFORMATION IMAGE

Technical information Also available:
•
ID cable ties
Humidity absorption 2,7% (50% relative humidity) • Releasable cable ties
Working temperature -40°C +85°C • Push mount cable ties
Tightening temperature -10°C +60°C • Cable ties with mounting hole
• Cable tray Ties
Max admissible point +110°C for short time • Big variety of mounting bases etc.
Melting temperature +256°C • Identification plate bases
Limit Oxygen Index 27%
Flammability rating UL 94 class V2
Dielectric strength 50.000 volts/mm
According to EN 50 146

Dimensions
Code Dimensions Code Dimensions Code Dimensions
Natural / Black (mm) Natural / Black (mm) Natural / Black (mm)
5201 / 5301 2,2*75 5217 / 5317 4,8*290 5237 / 5337 12,5*500
5203 / 5302 2,5*98 5218 / 5318 4,8*390 5239 / 5339 12,5*720
5205 / 5305 2,5*135 5219 / 5319 4,8*360 5241 / 5341 12,5*850
5206 / 5306 2,6*160 5220 / 5320 4,8*430 5243 / 5343 12,5*1000
5207 / 5307 2,6*200 5221 / 5321 7,8*120 - -
5208 / 5308 3,6*370 5223 / 5323 7,8*180 - -
5209 / 5309 3,6*140 5225 / 5325 7,8*240 - -
5210 / 5310 3,6*290 5226 / 5326 7,8*300 - -
5211 / 5311 4,5*160 5227 / 5327 7,8*365 - -
5212 / 5312 4,5*120 5229 / 5329 7,8*450 - -
5213 / 5313 48*178 5231 / 5331 7,8*540 - -
5214 / 5314 3,6*200 5233 / 5333 7,8*750 - -
5215 / 5315 4,8*200 5234 / 5334 9,0*780 - -
5216 / 5316 4,8*250 5235 / 5335 12,5*225 - -

02
