A141 SIGNALLING
High level audible warning SIGNALLING

system

The A141 is the latest in a new generation of
high output electronic sounders from E2S which
are ideal for wide area and disaster warning
applications such as COMAH (Seveso II) Alarm,
Toxic Gas Release, Fire, Security, Flood Warning,
Tsunami Alert and Civil Defence requiring sound
coverage up to 750m.

PRODUCT PRODUCT AVAILABLE
INFORMATION IMAGE COLOURS

With a choice of 45 standard warning tones including many of the standard international signals the A141 can offer up to 4 different stages of alarm. A
“Hootronic” version of the A141 is also available which replicates the traditional signaling sounds of bells, buzzers, sirens and hooters. By re-playing digital
recordings of these products, the Hootronic produces the exact sound but without the reliability and rating problems of electro-mechanical devices. Marin
Supply AS has considerable experience in this field and is able to offer full pre and post installation support including assistance with siren selection.

Horn unit Features
Using four 100W drivers, the A141 produces a powerful
Maximum output 141dB(A) @ 1 metre (Effective distance 400-700m) sound with an output in excess of 140 dB and is ideal
No. of tones 45 (UKOOA/PFEER compliant for warning over distances of between 400m and 700m.
No. of stages 3 The A141 has a lightweight, compact housing designed
Horn body Material Glass fibre reinforced plastic for easy mounting and is protected to IP65 making it
suitable for installation in all locations.
Dimensions (L) 680 X (H) 425 X (D) 550 mm
Connection Supplied with 10m of cable for connection to the Optional extras include:
control unit as standard. Custom lengths available. • Custom Tones
• Battery Back Up (giving up to 30 minutes of alarm)
Mounting Adjustable U bracket
• Radio Control
Control Panel
Input voltage DC 24Vdc (18Vdc to 30Vdc range)
Input voltage AC 115 or 230Vac (90V to 264Vac range)
Terminals 0.5 to 4.0mm² cable

Horn colours: 01 - WIDE AREA AUDIBLE

IP IP

14kg 2,9kg 65 65 -20ºC / + 55ºC
(Horn unit) (Control Panel) (Horn unit) (Control Panel)
