Sanders

orbital and random orbital
for coated abrasives

LST/LSO orbital and random orbital sanders are
designed to give you the best surface result in the
shortest possible time before painting and coating.
They are also suitable for polishing with wax and
surface conditioner.
All models are lubrication and silicone free to avoid
contamination of the workpiece.
LST30
They are available in standard versions, self-suction,
or central suction.

LST20 LST21 LST22 LSO30

Air con-
Max Max Max Height sumption Rec Handle
free out- pad Orbit over at free hose Air inlet
speed put size dia Weight spindle speed size thread
Model r/min W mm mm kg mm l/s mm BSP With Without Ordering No.
Random orbital - Standard
LST30 H090-11 9000 300 110 8 1.2 120 7.5 8 1/4'' ● - 8423 0361 64
LST30 H090-15 9000 300 150 8 1.2 120 7.5 8 1/4'' ● - 8423 0361 72
LST30 S090-15 9000 300 150 8 1.1 120 7.5 8 1/4'' - ● 8423 0361 98
Self suction a
LST31 H090-15 9000 300 150 8 1.4 120 7.5 8 1/4'' ● - 8423 0363 19
Central suction b
LST32 H090-15 9000 300 150 8 1.4 120 7.5 8 1/4'' ● - 8423 0362 55
LST32 S090-15 9000 300 150 8 1.3 120 7.5 8 1/4'' - ● 8423 0362 71
Orbital - Standard
LSO30 S070-3 7000 300 93x170 5 1.6 125 7.5 8 1/4'' - ● 8423 0360 16
LSO30 H070-3 7000 300 93x170 5 1.7 125 7.5 8 1/4'' ● - 8423 0360 24
Central suction c
LSO32 H070-3 7000 300 93x170 5 1.8 125 7.5 8 1/4'' ● - 8423 0361 07
Standard model
LST20 R350 12000 200 90 5 0.85 95 8 8 1/4'' - ● 8423 0361 65
LST20 R550 12000 200 125 5 0.85 83 8 8 1/4'' - ● 8423 0361 69
LST20 R650 12000 200 150 5 0.85 83 8 8 1/4'' - ● 8423 0361 73
LST20 R525 12000 200 125 2.4 0.85 83 8 8 1/4'' - ● 8423 0361 81
LST20 R625 12000 200 150 2.4 0.85 83 8 8 1/4'' - ● 8423 0361 84
Extraction model - Self suction
LST21 R550 d 12000 200 125 5 0.85 83 8 8 1/4'' - ● 8423 0361 70
LST21 R650 d 12000 200 150 5 0.85 83 8 8 1/4'' - ● 8423 0361 74
Extraction model - Central suction
LST22 R550 d 12000 200 125 5 0.85 83 8 8 1/4'' - ● 8423 0361 71
LST22 R650 d 12000 200 150 5 0.85 83 8 8 1/4'' - ● 8423 0361 75
a Includes dust collecting bag.
b Required air flow 150 m 3 /h or 88 cfm.
c Required air flow 60 m 3 /h or 35 cfm.
d 186 mm (7.3") suction hose connector included.
46 Material removal tools
