Vibration and Noise Emission Values Vibration and Noise Emission Values

Material removal tools

Vibration Sound Vibration Sound
total value pressure levels total value pressure levels
(3 axes value) and sound (3 axes value) and sound
according to power levels a according to power levels a
ISO 28927-12 according to ISO 28927-4 according to
Valid from 2010 ISO 15744 Valid from 2010 ISO 15744
Value Uncer- Sound Sound Value Uncer- Sound Sound
3-axes tainty pressure power 3-axes tainty pressure power
Model m/s 2 m/s 2 dB(A) dB(A) Model m/s 2 m/s 2 dB(A) dB(A)
Grinders Grinders
Die grinder Straight
Straight LSR48 S120-CW <2.5 - 80 -
LSF19 S460-1 4.7 2 81 92 LSR48 S090-CW 3.6 0.9 76 -
LSF19 S200E-1 3.1 1.8 <70 - LSR28 S180-05 <2.5 - 85 96
LSF19 S300E-1 3.4 1.8 73 - LSR28 S150-10 <2.5 - 70 -
LSF19 S300E-1/R 3.3 1 73 - LSR28 S110-08 <2.5 - <70 -
LSF19 S460E-1 4.7 2 81 92 LSR43 S150-10 2.9 1 86 97
LSF19 S460E-1/R 3.6 1.3 81 92 LSR43 S120-08 <2.5 - 84 95
LSF19 S300-1/R 3.2 2.2 73 - LSR43 S090-10 <2.5 - 82 93
LSF38 S150E-01/R <2.5 - 81 92 LSR48 S120-08 <2.5 - 78 -
LSF38 S180E-01/R <2.5 - 86 97 LSR48 S120-08R <2.5 - 78 -
LSF38 S180E-01 <2.5 - 86 97 LSR48 S120-13 2.9 1.2 83 94
LSF38 S250E-01 2.8 1.3 90 101 LSR48 S120-10 <2.5 - 80 -
LSF28 S180 2.8 1.1 74 - LSR48 S090-10R <2.5 - 78 -
LSF28 S180E <2.5 - 74 - LSR64 S100-15 <2.5 - 88 99
LSF28 S250 2.7 0.7 81 92 LSR64 S072-13 <2.5 - 82 93
LSF28 S180-1R 3.4 0.9 74 - LSR64 S060-15 <2.5 - 83 94
LSF28 S180E-1R 2.8 1 74 - LSR28 ST070E-CW 3.1 1.1 81 92
LSF28 S250-R 3.1 1.8 81 92 LSR43 S072 <2.5 - 83 94
LSF28 S250E-R 3 0.7 81 92 LSR28 ST070E-CW 3.1 1.1 81 92
LSF28 S250E <2.5 - 81 92 LSR43 S072 <2.5 - 83 94
LSF28 S150E <2.5 - <70 -
LSF28 ST030E 2.7 1.5 74 - Vibration Sound
LSF28 ST030 <2.5 - 74 - total value pressure levels
LSF28 S150 3.6 1.2 <70 - (3 axes value) and sound
LSF28 ST070E 2.7 1.2 81 92 according to power levels a
ISO 28927-1
LSF28 ST070 <2.5 - 81 92 Valid from 2010 according to
ISO 15744
LSF28 S120 2.8 0.7 <70 -
LSF07 S850 <2.5 - 75 - Value Uncer- Sound Sound
Angle 3-axes tainty pressure power
2
2
LSV12 S200-1 4.3 2.1 78 - Model m/s m/s dB(A) dB(A)
Grinders
LSV12 S120-1 3.2 2 75 - Vertical grinder
LSV19 S200-1 <2.5 - 75 -
-
LSV19 S120-1 <2.5 - 75 - LSS53 S085-18 3.8 1.1 78 97
86
1.5
4.6
LSS64 S085-18
LSV19 S080-1 <2.5 - 73 - LSS53 S072-C13 2.8 1.3 76 -
LSV18 S080 <2.5 - 73 -
LSS64 S060-C15 <2.5 - 82 93
LSS64 S060-23 3.9 1.2 82 93
Vibration Sound LSS84 S060-23 3.9 1.2 88 99
total value pressure levels
(3 axes value) and sound Angle grinders
according to power levels a LSV19 S170-08 7.9 2.4 80 -
ISO 28927-4 according to LSV28 ST13-10E 8.3 2.8 81 92
Valid from 2010 ISO 15744 LSV28 ST12-10 4 1.3 86 97
Value Uncer- Sound Sound LSV28 ST12-12 5.3 1.6 86 97
3-axes tainty pressure power LSV28 ST12-13 5.6 1.7 86 97
Model m/s 2 m/s 2 dB(A) dB(A) LSV28 S060-18 4.5 1.4 81 92
Grinders LSV38 S12-125 5.2 1.6 85 96
Straight LSV38 ST12-125 4.9 1.5 85 96
LSR28 S150-CW 2.8 1.2 70 - LSV38 SA12-125 3.3 0.8 85 96
LSR28 S120-CW <2.5 - <70 - LSV48 SA120-13 4.8 1.1 89 100
LSR38 S180-CW 4 1.3 83 94 LSV48 SA085-18 3.9 0.9 89 100
LSR38 S150-CW 2.6 0.8 85 96 LSV48 SA066-23 3.9 1.6 89 100
LSR48 S150-CW <2.5 - 80 -
a The uncertainty in the sound levels is 3 dB(A).
