BPC Range - Control Stations
The BPC range of control stations have been designed for use in potentially explosive atmospheres and
are suitable for most gas groups including hydrogen. Based on the popular BPGC range of enclosures,
they are manufactured from carbon loaded glass reinforced polyester (GRP). This material gives excellent
mechanical strength and life expectancy, making these control stations particularly suitable for use in
harsh environmental conditions. Additionally, the anti-static properties of the enclosure material make
them ideal for use in dust hazard environments. A number of common actuator types can be fitted,
including Start, Stop, Emergency Stop and rotary type switches. Tag and individual actuator labels can be
fitted as required.
Features
• Application :Industrial and Hazardous areas
• Protection Degree: IP66
• Certification :ATEX II 2 GD EEx ed IIC T4 IEC Ex
• Material: Carbon Loaded Glass Reinforced Polyester (Black)
• Temperature Rating: -40o to 80o C (-40o to 176o F)
• Maximum Voltage: 415V
• Maximum Switching Current: 6A

SXC Range - Control Stations
The SXC range of control stations have been designed for use in potentially explosive atmospheres
and are suitable for all gas groups including hydrogen. Based on the SX range of enclosures, they
are manufactured from high quality 316 stainless steel. This material offers the highest degree of
environmental protection and is suitable for even the most arduous of conditions. Additionally, stainless
steel prevents the build up of static electricity, making these controls stations ideal for use in dust hazard
applications.
Features
• Application :Industrial and Hazardous areas
• Protection Degree: IP66
• Certification :ATEX II 2 GD EEx ed IIC T4 IEC Ex
• Material: Stainless steel 316 (1.4404)
• Temperature Rating: -40o to 80o C (-40o to 176o F)
• Maximum Voltage: 415V
• Maximum Switching Current: 6A
